High Frequency Ultrasonic Elliptical Vibration Turning Studty for Weak Rigidity Precision Workpiece

Abstract:

Based on analysis of the micro-surface and kinematical formulas of elliptical vibration cutting(EVC), the paper presents that frequency and amplitude of vibration parameter affect surface roughness, forming accuracy and machining efficiency of weak rigidity workpiece: increase vibration frequency are result in lower vibration cutting duty cycle , lower cutting force, advancer critical speed, so advance forming accuracy and machining efficiency; decrease amplitude are result in reduce the height of vibration ripples in cutting direction , so improve surface roughness. Experiences of cutting the weak rigidity workpiece by the designed double bending hybrid vibration high transducer, verified that the high frequency elliptical vibration cutting are proved more conducive to machining weak rigidity workpiece.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 236-240
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.236
• Online since: February 2011
• Authors: Wen Li, De Yuan Zhang
• Keywords: Elliptical Vibration Cutting, Higher Frequency, Machining Accuracy, Machining Efficiency, Surface Roughness (SR)

References

[1] Ma Chun-xiang, Pan Ming-yue, Wang Hai-li. Ultrasonic Elliptical Vibration Cutting for Weak Rigidity Workpiece[J]. Journal of Nanjing University of Aeronautics & Astronautics. Vol. 37(2005) , p.121.

[2] Chandra Nath, M. Rahman, Effect of machining parameters in ultrasonic vibration cutting. Journal of Machining Tools &manufacture . Vol. 48(2008), p.965.

DOI: 10.1016/j.ijmachtools.2008.01.013

[3] Li Xun, Zhang Deyuan. Research on Micro-surface Formation Mechanism of Ultrasonic Elliptical Vibration Cutting, China Mechanical Engineering. Vol. 20 (2009), p.807.

DOI: 10.1109/mace.2010.5536427

[4] Shamoto E, Moriwaki T. Ultrasonic precision diamond cutting of hardened steel by applying ultrasonic elliptical vibration cutting [J ]. Annual of CIPR. Vol. 48(1999), p.441.

DOI: 10.1016/s0007-8506(07)63222-3

[5] Shamoto E,. Moriwaki T. Elliptical vibration cutting [J]. Annuals of CIPR. Vol . 43(1994), p.35.

[6] Zhang Deyuan. The Mechanism of Precision Cutting in Vibration Cutting [J]. Journal of Beijing University of Aeronautics and Astronautics. No. 4(1993),. p.61.

[7] Tobias S A, Fishwick W. The chatter of lath tools under orthogonal cutting conditions [J]. Trans ASME, Vol 80(1958), p.1079.

DOI: 10.1115/1.4012610

[8] V.I. Babitsky, A.V. Mitrofanov, V.V. Silberschmidt, Ultrasonically assisted turning of aviation materials: simulations and experimental study, Ultrasonic Vol. 42 (2004), p.81–86.

DOI: 10.1016/j.ultras.2004.02.001

[9] A.V. Mitrofanov, et al., Finite element simulations of ultrasonic ally assisted turning, Computational Materials Science. Vol 28(2003), p.645.

DOI: 10.1016/j.commatsci.2003.08.020
