Predicting Dimensional Accuracy of Mechanically Joined Car Body Assemblies

Abstract:

Mechanical joining of complex car body components is an essential part of lightweight construction concepts in the field of car body manufacturing. Besides the mechanical behavior of the joints, the influence on the dimensional accuracy is of particular interest, as joining techniques like clinching or self-piercing riveting cause distortion comparable to spot welding. In recent years, a lot of simplified models using the FE-Method to predict the distortion of assemblies caused by welding (weld seams, spot welds) were presented and commercialized. In contrast to thermal joining technologies, there are no such simplified models with practical relevance existing in the mechanical joining technology sector. In this paper, a new method to predict distortion, caused by different mechanical joining technologies, including effects from previous forming processes, and clamping conditions, is presented. The validation of the simplified model takes place due to an extensive design of expe-riments. It can be proved that the distortion of simple as well as of complex specimens can be relia-bly predicted.

• Periodical: Key Engineering Materials (Volume 473)
• Pages: 973-980
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.473.973
• Online since: March 2011
• Authors: Reimund Neugebauer, Markus Rössinger, Martin Wahl, Frank Schulz, Alexander Eckert, W. Schützle
• Keywords: Distortion, Finite Element Model (FEM), Mechanical Joining, Process Chain, Simplified Model

References

[1] W. Cai, P.C. Wang, Wu Yang: International Journal of Machine Tools & Manufacture 45 (2005) 695-704.

[2] H. Iguchi and Y. Ohmi: JSAE20037065, Japan (2003).

[3] R. Neugebauer, M. Israel: EFB-Forschungsbericht Nr. 294.

[4] Ch. Stapelfeld, N. Doynov, V. Michailov: Sysweld Forum (2009).

[5] S. Xu, X. Deng: Finite Elements in Analysis and Design 40 (2004) 1175-1194.

[6] X. He, I. Pearson, K. Young: Journal of materials processing technology 199 (2008), 27-36.

[7] P.R. King: Ph.D. thesis , (1997).

[8] R. Khezri: Swedish Institute for Metal Research Report No. IM-2000-25.

[9] O. Hahn, N. Dölle: Universität Paderborn, LWF Schriftreihe 48, Shaker Verlag, Aachen, ISBN3-8265-9427-4, (2001).

[10] O. Hahn, A. Chergui: Forschungsbericht Nr. 193, Hannover, (2005).

[11] N. Dölle, J.R. Kurzok, A. Chergui: Chinese-German Ultralight Symposium, Vorträge zum Symposium, DVS-Bericht 218, 225-240, (2001).

[12] S.C. Liu, S.J. Hu: Journal of Manufacturing Science and Engineering 119 (3) (1997) 368-374.

[13] J. Camelio, S.J. Hu, D. Ceglarek: DET-C2001/ASME, Pittsburg, PA Sept. 10-12 (2001).

[14] R. Neugebauer, F. Jesche, M. Israel: International ESAFORM Conference, Brescia, (2010).

[15] AiF-IGF-Verbundprojekt (IFS, IWB, IWM, LFT), (2010).
