Effect of Oxide Film Thickness on Stress-Strain Field at the Tip of Stress Corrosion Cracking

Abstract:

Environmentally assisted cracking (EAC) or stress corrosion cracking (SCC) of key structural materials in the environments of the light water reactor is one of the main problems for the management of the structural safety and service life of nuclear power plants. To understand the effect of oxide film thickness on SCC growth in structural materials in a high temperature water environment, the stress-strain field at the tip of a SCC in nickel base alloy constituted by base metal and oxide film was analyzed in this paper by finite element method using commercial software. The effects of oxide film thickness on the stress-strain field at the tip of the SCC was obtained, which provides a new insight into the research of the mechanism of SCC growth in structural materials in a high temperature water environment.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 1128-1131
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.1128
• Online since: April 2011
• Authors: Wei Tang, He Xue, Dan Zhao
• Keywords: Nickel Base Alloy, Oxide Film, Strain, Stress, Stress Corrosion Cracking (SCC), Yield Strength

References

[1] O. K. Chopra, H. M. Chunga, T. F. Kassnera, J. H. Parka, W. J. Shacka, J. Zhangb, F. W. Brustb and P. Dong. Current research on environmentally assisted cracking in light water reactor environments. Nuclear Engineering and Design, 1999, 194(1-2): 205-223.

DOI: 10.1016/s0029-5493(99)00206-x

[2] H. Xue and T. Shoji. Quantitative prediction of EAC crack growth rate of sensitized type 304 stainless steel in boiling water reactor environments based on EPFEM. Transactions of the ASME- Journal of Pressure Vessel and Technology, 2007, 129(3), 254-258.

DOI: 10.1115/1.2748827

[3] Jianshu LU, Baofeng WANG, Jiuyuan ZHANG. A Review of Stress Corrosion Cracking Studies of Stainless Steels and Nickel Base Alloys in High Temperature Water. Nuclear Power Engineering, 2001, 22 (3), 259-263.

[4] P.L. Andresen, K. Gott and J.L. Nelson. Stress corrosion cracking of sensitized type 304 stainless steel in 288°C water: a five laboratory round bobbin, Proceedings of the 9th International Symposium on Environmental Degradation of Material in Nuclear Power Systems-Water Reactors, S. Bruemmer, et al eds., Newport Beach, California, 1999, 423-433.

DOI: 10.1002/9781118787618.ch43

[5] H. Xue, Y. Sato and T. Shoji. Quantitative estimation of the growth of environmentally assisted cracks at flaws in light water reactor components. Transactions of the ASME- Journal of Pressure Vessel and Technology, 2009, 131(1), 61-70.

DOI: 10.1115/1.3027458

[6] D. C. Lagoudas, P. Entchev and R. Triharjanto. Modeling of Oxidation and its Effect on Crack Growth in Titanium Alloys. Computer Methods in Applied Mechanics and Engineering, 2000, 183(1-2): 35-50.

DOI: 10.1016/s0045-7825(99)00210-8

[7] ASTM Standard E399-90. Standard test method for plane strain fracture toughness of metallic materials, Annual book of ASTM Standards, Vol. 03. 01, ASTM International, (2002).

DOI: 10.1520/stp33670s

[8] ABAQUS/Standard User's Manual. Version 6. 5, Pawtucket, RI, Hibbitt, Karlsson & Sorensen, Inc. (2004).

[9] H. Xue, K. Ogawa and T. Shoji. Effect of welded mechanical heterogeneity on local stress and strain in stationary and growing crack tips, Nuclear Engineering and Design, 2009, 236(5), 628-640.

DOI: 10.1016/j.nucengdes.2008.12.024

[10] T. Terachi, K. Fuji and K. Arioka. Microstructure Characterization of SCC Crack Tip and Oxide Film for SUS 316 Stainless Steel in Simulated PWR Primary Water at 320°C. Nuclear Science and Technology, 2005, 42(2), 225-232.

DOI: 10.1080/18811248.2005.9726383

[11] Q.J. Peng, J. Kwon, T. Shoji. Development of a fundamental crack tip strain rate equation and its application to quantitative prediction of stress corrosion cracking of stainless steels in high temperature oxygenated water. Journal of Nuclear Materials, 2004, 324(1), 52-61.

DOI: 10.1016/j.jnucmat.2003.09.008
