Application of Numerical Simulation on Cast-Iron Pneumatic Hammer Housing

Abstract:

The Pro/E software was used to generate 3-D model of pneumatic hammer housing casting. The solidification process of the casting was simulated by the numerical simulation software, View Cast. The location and scale of the shrinkage defects were shown in the results. The risers were designed by the View Cast software based on the simulation results. The reasonable risers were obtained after the optimization on the numerical simulation. And the parameters of gating system were got according to the simulation results calculated by the gating system designing function of View Cast. Then the solidification results demonstrated that the risers and pouring system could be planned by View Cast effectually. The reasonable casting process was obtained and the process has been proofed by the productive practice.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 432-435
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.432
• Online since: April 2011
• Authors: Guo Fa Mi, Li Lin Chen, Bao Zhong Liu, Hai Yan Wang
• Keywords: Casting Process, Numerical Simulation, Pneumatic Hammer Housing

References

[1] E. Niyama: AFS(1981) Vol. 6(1981), p.16.

[2] Y.Y. Li, D. Zh. Li, M.Y. Zhu: Computer Simulation of Metal Processing (Science Press, China 2006).

[3] T. Jing: Mumerical Simulation in Solidification Process (Publishing House of Electronics Industry, China 2002).

[4] ZH.A. Xu: View Cast users manual (Belgium 2010).

[5] G.F. Mi, Y.L. Liu, B. Zhang: Foundry Vol. 58 Iss. 2(2009), p.141.

[6] F. Mampaey, Zh.A. Xu, in: Modeling of Casting, Welding and Advanced Solidification ProcessesⅦ, ed. by M. Cross and J. Campbell / Warrendale, PA: TMS (1995).
