Influence of Ar+ Energy of Bombardment Cu Target and Low Energy Assisted Bombardment on Cu-W Thin Film Structure by Ion Beam Sputtering

Abstract:

This paper is to study the influence of Ar+ energy of bombardment Cu target and low energy assisted bombardment on Cu-W film structure in the preparation of Cu-W thin film by dual ion beam sputtering technique with iron as the substrate and argon as ion source. The results shown : when Ar+ energy of bombardment tungsten target is about 3keV, the beam of copper target is 20mA, Ar+ energy of bombardment Cu target is 1kev, 1.5kev and 2keV respectively, Cu-W thin film prepared by ion beam sputtering exists with the skeleton of tungsten in amorphous phase mixing with copper grains; with the increase of Ar+ energy of of bombardment copper target, the grain size of copper increases slightly; influenced by crystal defects and lattice distortion, copper diffraction peak offsets a little. Low energy assisted bombardment helps to increase grain growth of copper and can decrease crystal defects and lattice distortion. But with excessive energy, thin film fails to deposit.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 448-453
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.448
• Online since: April 2011
• Authors: Yong Ping Ai, Ying Ying Zeng, Li Jun Liu, Xiao Ming Huang, Tai Ping Zhou
• Keywords: Amorphous Phase, Cu-W Alloy, Dual Ion Beam Sputtering, Thin Film

References

[1] Y.P. Li, X.H. Qu, Z.S. Zheng, C.G. Lei, Z.Q. Zou, S. Yu, International Journal of Refractory Metals & Hard Materials. Vol. 21 (2003), p.295.

[2] A Paul, T. Damm, D. E BÜrgler, S. Stein, H. Kohlstedt and P. GrÜnberg, Journal of physics: condensed matter. Vol. 15 (2003), p.2471.

[3] F. Yang, T. He, F. Zeng and F. Pan, Journal of physics: condensed matter. Vol. 14(2002), 1775.

[4] R. Gago1, L. Vazquez1, R. Cuerno, M. Varela, C. Ballesteros and J. M Albella1, Nanotechnology. Vol. 13 (2002), p.304.

[5] J. Pacaud, G. Gladyszewski, C. Jaouen, Appl. Phys. Vol. 73 (1993), p.2786.

[6] M. Oron C.M. Adams, Appl phys. Vol. 40(1968), p.4218.

[7] J. P. Chu, C. J. Liu, C. H. Lin, Materials Chemistry and Physics. Vol. 72(2001), p.286.

[8] W.Z. Tang, Principles, Technology and Application of Thin Film Material Preparation. Beijing: Metallurgy Industry Press, 2003, p.169 (in china).

[9] J.S. Tang. Technology and Application of ion beam Deposition of Thin Films. Beijing: National Defense Industry Press, 2003, p.13. (In China).

[10] C. Wang, P. Brault, C. Zaepffel, Phys. D: Appl. Phys. Vol. 36(2003) , p.2709.
