Configuration Design and Kinematic Analysis on Some New 2R1T 3-DOF Parallel Robots

Abstract:

Based on the screw theory,the paper presents a systematic method for structural synthesis of the two rotations and one translation parallel robot.According to the reciprocal product between kinetic screw and constrainted screw in screw theory.This method firstly creats possible branch structures and then generates diferent models of mechanism.By this method,the paper carries on the structural synthesis of the two rotations and one translation parallel robot,and also lists some of the mechanisms including a few new ones. Analyzsis solution of direct and inverse position.The dynamic simulation was conducted using the software of Adams.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 840-845
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.840
• Online since: April 2011
• Authors: Da Chang Zhu, Fan Xiao, Liang Wang, Qi Hua Gu
• Keywords: Kinematics, Parallel Manipulator, Screw Theory, Simulation

References

[1] Qinchuan Li and Zhen Huang: Type Synthesis of 4-DOF Parallel Manipulators, International Conference an Robotics & Automation September 14-19, (2003).

DOI: 10.1109/robot.2003.1241684

[2] Jaime Gallardo-Alvaradoa, Gursel Alicib, Kinematics and singuarity analyses of a 4-dof parallel manipulator using screw theory, Mechanism and MachineTheory41(2006)1048-1061.

DOI: 10.1016/j.mechmachtheory.2005.10.012

[3] Z. Huang and Q. C. Li, Some novel lower-mobility parallel mechanism, in Proc. of ASME 2002 Design Engineering Technical Confenences, Montreal, Canada, MECH-34299.

[4] Paul G. Ranky. Reconfigurable robot tool designs and integration applications, Industrial Robot, Volume 30. Number 4. 2003. 338-344.

DOI: 10.1108/01439910310479603

[5] Tsai L W and Joshi S. Kinematics and Optimization of a Spatial 3-UPU Parallel Manipulator. Trans. ASME, Journal of Mechanical Design, vol. 122, pp.439-446, (2000).

DOI: 10.1115/1.1311612

[6] Hai Rong Fang, Less dof parallel robot mechanism structure synthesis method research, Doctoral dissertation, (2005).

[7] T. S. Zhao and Z. Huang, A novel spatial fow-dof parallel mechanism and its position analysis, Mechanical Science and Technology, vol. 19(6), 2000, pp.927-929.

[8] TANEV T K. Kinematics of a hybrid(parallel—serial)robot manipulator[J]. Mech Mach Theory. 2000, 35(6): 1183-1196.

DOI: 10.1016/s0094-114x(99)00073-7

[9] Marco Carricato, Vincenzo Parenti-Castelli. Position Analysis of a New Family of 3-DOF Translational Parallel Manipulators. ASMEJ. Mech. Des, 2003, Vol. 125: 316-322.

DOI: 10.1115/1.1564073

[10] Meng-shiun Tsai, Ting-Nung Shiau, Yi-Jeng Tsai, Tsann-Huei Chang. Direct kinematics analysis of a 3-PRS parallel mechanism. Mechanism and Machine Theory, 2003, 38: 71-83.

DOI: 10.1016/s0094-114x(02)00069-1

[11] J, Pmerlet. Optimal Design for the Micro Parallel Robot MIPS. IEEE International Conference on Robotics and Automation[C], Washington, 2002: 1149-1154.
