Study on Flow Field in Different Styles of Blades for Eddy Current Retarder’s Rotor Based on CFD

Abstract:

Eddy current retarder was a retarder braking set used in an automobile, and it can transform kinetic energy or mechanical energy of the automobile into heat energy, and heat energy was emitted around environment by the blades founded in the rotor of eddy current retarder, so flow field within the blade had direct effect on heat elimination and braking performance. In this paper two styles of 2D computational model for the rotor had been established. The flow field between and out of blades were analyzed by using RNG Κ-ε model and energy equation. The velocity distribution, pressure distribution between blades, static pressure on work face and rear face of the blade along radial direction all were accepted. The pressure, velocity and air flux for two styles of the blades had been compared. Numerical analysis of flow field was in favor of improved structure design for the blade.

• Periodical: Key Engineering Materials (Volumes 480-481)
• Pages: 1134-1139
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.480-481.1134
• Online since: June 2011
• Authors: Jian Ming Shen, Cheng Ye Liu
• Keywords: Automotive Engineering, Computational Fluid Dynamics (CFD), Eddy Current Retarder, Flow Field, RNG K-ε Turbulent Model

References

[1] Yi Fengyan, Yu Mingjin, Liu Chengye. 3D Numerical Simulation of Eddy Current Brake[J]. Journal of System Simulation, 2010, 22(7): 1592-1595.

[2] Liu Chengye. Review on Development of Auxiliary Braking Set[J]. China Safety Science Journal, 2008, 18(1): 105-111 (in Chinese).

[3] Liu chengye, Jiang kejun, Zhang yan. Study on Temperature Rise Performance of Eddy Current Retarder in Automobile[C]. 2010 International Conference on Future Information Technology and Management Engineering, October 9-10, 2010. Changzhou, China. Volume 1: 550-553.

DOI: 10.1109/fitme.2010.5655807

[4] Scott Kimbrough. Optimal control of Electromagnetic Brake Retarders[C]. SAE paper, 942325.

DOI: 10.4271/942325

[5] HE Ren, LIU Cheng-ye, YI Feng-yan. Computation Method for Thermal Field of Eddy Current Retarder in Automobile[J]. Journal of Jiangsu University (Natural Science Edition), 2005(2): 117-120.

[6] Liu Chengye, He Ren, Yi Fengyan. Flow Field Analysis of Eddy Current Retarder in Automobile[J]. Automotive Engineering, 2005(4): 25-29.

[7] Smith G D. Numerical solutions of partial differential equations (finite difference methods). 3rd edition [M]. Oxford: Clarendon Press, (1985).

[8] Bernatz R, Carlson K D, Lin W L. Finite analytic method in flows and heat transfer[M]. New York: Taylor & Francis, (2000).

[9] V. Yakhot and S. A. Orszag. Renormalization Group Analysis of Turbulence[M]. I. Basic Theory. Journal of Scientific Computing, 1986, 1(1): 1-51.

DOI: 10.1007/bf01061452
