Experimental Research on Dynamic Characteristics of Synthetic Jet Induced by SJA with HCPCS Membrane

Abstract:

A new half cymbal style piezoelectric-metal composite structure (HCPCS) membrane is proposed and utilized for piezoelectric synthetic jet actuator (PSJA) to increase its output jet velocity. PSJA specimens with both plane and HCPCS membranes were manufactured. An experimental system with hot-wire anemometer was setup to test the jet velocity. The frequency responses of time-averaged jet velocity were measured for both HCPCS diaphragms and plane membranes. The time-averaged velocity distributions were collected along the exit centerline. Experiments indicate that the HCPCS structure brings a promotion of vibration displacement distortion of diaphragm and stronger driving capability, and that the mean jet velocities synthesized from the optimal HCPCS PSJAs are higher than the optimal plane membrane one. Hilbert-Huang Transform was employed to analyze the instantaneous energy distribution characteristics of the jet. The analysis was done for signals along the centerline. The results show that HHT is an effective method for fluid field analysis.

• Periodical: Key Engineering Materials (Volumes 480-481)
• Pages: 329-334
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.480-481.329
• Online since: June 2011
• Authors: Yong Zhou, Bang Feng Wang, Wei Wang, Yong Cheng, Feng Wang
• Keywords: Composite Structure, Cymbal, HHT, Piezoelectric, Synthetic Jet Actuator

References

[1] C. Lee, G. Hong, Q.P. Ha et al. A piezoelectrically actuated micro synthetic jet for active flow control, Sensors and Actuators A, 108 (2003), pp.168-174.

DOI: 10.1016/s0924-4247(03)00267-x

[2] J.L. Gilarranz, L.W. Traub, O.K. Rediniotis. Characterization of a Compact, High-Power Synthetic Jet Actuator for Flow Separation Control, AIAA 2002-0127.

DOI: 10.2514/6.2002-127

[3] Z. Travnicek, V. Tesar. Annular synthetic jet used for impinging flow mass-transfer, International Journal of Heat and Mass Transfer, 46 (2003), pp.3291-3297.

DOI: 10.1016/s0017-9310(03)00119-4

[4] K.R. Grossman, B.Z. Cybyk, M.C. Rigling et al. Characterization of Sparkjet Actuators for Flow Control, AIAA 2004-0089.

DOI: 10.2514/6.2004-89

[5] M. Karla, M. Poorna. Velocity Profiles of Synthetic Jets using Piezoelectric Circular Actuators. AIAA 2005-2341.

[6] B.F. Wang, Y. Zhou, H.S. Qian. Research on Piezoelectric Synthetic Jet Actuator with Cymbal Membrane, 18th International Conference of Adaptive Structure and Technology(2007).

[7] Y. Guy, T.E. McLaughlin and J. A. Morrow. Velocity Measurements in a Synthetic Jet, AIAA 2001-0118.

[8] S.G. Mallinson, J.A. Reizes, G. Hong et al. Analysis of hot-wire anemometry data obtained in a synthetic jet flow, Experimental Thermal and Fluid Science, 28(2004), pp.265-272.

DOI: 10.1016/j.expthermflusci.2003.05.001

[9] N.E. Huang, S. Zheng, S.R. Long et al. The Empirical Mode Decomposition and Hilbert Spectrum for Nonlinear and Non-stationary Time Series Analysis. Proceedings of the Royal Society of London, Series A, 1998, 455: 903-995.

DOI: 10.1098/rspa.1998.0193
