Turbulence Flow Analysis of Low Temperature Propellant Flowing through Pipes of Filling System

Abstract:

With aiming at the problem of liquid hydrogen flowing through filling system in space launch site, the author set up a turbulence model and coupled with the analysis of turbulence condition of liquid hydrogen in tube. Based on the computational fluid dynamics, the flow field was studied according to the numerical simulation method. Then, the changes of flow parameters i.e. pressure and velocity at the tube were observed. Simulation results showed that, in the inlet-section, there existed boundary-layer, besides, the velocity and pressure which changed continually was not stable until the liquid hydrogen flowed through on-way. In addition, in water-carrying section of turbulence flow, the velocity distribution was even and there was no obvious delamination which explained that the mix was intense. The velocity near the surface of the tube was about zero and the pressure turned to smaller with the increase of tube length. As a result of the pressure drop, there existed the loss of on-way. The above simulation results which provided the theoretical basis for liquid hydrogen study accorded with the actual condition.

You might also be interested in these eBooks

Materials Engineering for Advanced Technologies

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 480-481)

Pages:

585-589

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.480-481.585

Citation:

Cite this paper

Online since:

June 2011

Authors:

Jian Jun Song, Xiao Ping Du, Ji Guang Zhao, Jing Peng Chen, Qiao Wang, Bi Ming Feng, Xin Li, Yu Jiang

Keywords:

Filling System, Flow Turbulence, Liquid Hydrogen, Space Launch Site

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Lin Wang, Sen Zhang, Jiangsan Wang. The Research and Design of Hydraulic Pipeline Flow Velocity [J]. Hydraulics Pneumatics & Seals, 2010(4): 36-38.

Google Scholar

[2] Lihua Feng, Jiqing Feng. Numerical Simulation for Flow in Channel Bend Using Different Turbulence Models [J]. Journal of Irrigation and Drainage, 2008, 27(6): 55-57.

Google Scholar

[3] Shupeng Cai, Damei Li, Guoyu Jin. Investigation on Drag Reduction Effect with Coupling of Flexible Tubes and Turbulent Flow [J]. Journal of Yangtze River Scientific Research Institute, 2006, 23(3): 47-50.

Google Scholar

[4] Shupeng Cai, Chuanlin Tang, Damei Da. Experimental Study on Effect of Turbulent Drag Reduction and Character of Flow-excited Vibration for Flexible Tubes [J]. Journal of Water Resources architectural engineering, 2005, 3(3): 4-7.

Google Scholar

[5] http: /www. simwe. com.

Google Scholar
