Analysis on Dynamic Characteristics of High Speed Cylindrical Roller Bearing

Abstract:

A nonlinear dynamics analysis mathematical model for the high-speed cylindrical roller bearing was built up. Dynamic performance parameters were got by Newton - Raphson method . The rotational velocity regularities of rollers were analyzed at different radial loads. The distribution of minimum oil-film thickness and contact load between rollers and bearing ring raceway were obtained. The results showed that number of loaded rollers increased with the increase of radial loads at a certain speed. Rollers slip seriously at lower radial loads. The rotation speed was low. The minimum oil-film thickness between loaded rollers and inner raceways was less than that of outer raceways. The results were compared with the results of SHARBERTH and comparison was made with testing results. It showed that the dynamic characteristics analysis method of high speed cylindrical roller bearing was accurate, reliable,simple and convenient for practical engineering application.

• Periodical: Key Engineering Materials (Volumes 480-481)
• Pages: 980-985
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.480-481.980
• Online since: June 2011
• Authors: Yan Shuang Wang, Ning Ning Jin, Hai Feng Zhu
• Keywords: Cylindrical Roller Bearing, Dynamic Characteristic, High-Speed, Load Distribution, Minimum Oil-Film Thickness

References

[1] Jones A B. A General Theory for Elastically Constraind Ball and Radial Roller Bearings under Arbitrary Load and Speed Conditions[J]. Trans. ASME Journal of Basic Engineering, 1960, 82(2): 309-320.

DOI: 10.1115/1.3662587

[2] Harris F A. Rolling Element Bearing Dynamics[J]. Wear, 1973, 23: 311-317.

[3] Gupta P K. Advanced Dynamics of Rolling Elements[M]. New York: Springer-Verlag New York Inc, (1984).

[4] Ghaisas N, Wassgren C R, Sadeghi F. Cage Instability in Cylindrical Roller Bearings [J]. Journal of Tribology, 2004, 126: 681~689.

DOI: 10.1115/1.1792674

[5] WANG Jiu-gen, WANG Qing-jiu, ZHANG Wei-ming. Study on Dynamics of Rolling Bearings[J]. Bearing, 2007, 3: 40-45.

[6] Aramaki H. Rolling Bearing Analysis Program Package BRAIN[J]. Motion & Control, 1997, 3: 15-24.

[7] Stacke L E, Fritzson D. Dynamic Behavior of Rolling Bearings Simulations and Experimentals[J]. Proc. Inst. Mech., Part J. 2001, 215(6): 499-508.

[8] WU Yun-peng, ZHANG Wen-ping, SUN Li-hong. Study on Mechanics Model of Rolling Bearing and Its Development Trend[J]. Bearing, 2004, 7: 44-46.

[9] Harris T A. Rolling bearing analysis[M]. (Fifth Edition). New York: John Wiley& Sons Inc, (2006).

[10] WEN Shizhu, YANG Peiran. Elastic hydrodynamic lubrication[M]. Beijing：Tsinghua University Press, (1992).

[11] Deng Sier, Jia Qunyi, Wang Yanshuang. Principles of rolling bearing design[M]. Beijing: Standards Press of China, (2009).

[12] ZHANG Kui, LI Jian-hua. Analysis Calculation of Friction Moment for the Ball Bearings. Bearing, 2001, 1: 8-11.

[13] Schrand J B, Vdori R, Jones H J. Computer Program Operation Manual on SHARBERTH, A Computer Program for the Analysis of the Steady State and Transient Thermal Performance of Shaft-Bearing System[R]. King of Prussia, PA: Engineering & Research Center of SKF Industries, (1976).
