Design and Test of a Self-Oscillating Driving ASIC for a Low-Q Gyroscope Based on PI Controller

Abstract:

In this work, closed-loop self-oscillating driving circuits for gyroscopes based on DC PI controller are analyzed in theory. The condition for oscillation is achieved by solving electrical differential equation, and the effects of key factors on magnitude stability are discussed. Further, an ASIC based on PI controller is designed, which is verified by simulation. The test results of manufactured chip correspond with the theoretical analysis, showing that this ASIC is capable of driving low-Q gyroscopes at normal temperate and pressure. This theory for analysis and the designed chip contribute to guide the design of closed-loop driving for gyroscopes, also improving stability for oscillating circuits.

• Periodical: Key Engineering Materials (Volume 483)
• Pages: 396-400
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.483.396
• Online since: June 2011
• Authors: Guan Shi Wang, Xiao Wei Liu, Bing Jun Lv, Liang Yin, Yi Ming Jiang, Mu Tao
• Keywords: Closed-Loop Self-Oscillating, PI Controller, Stability

References

[1] Mikko, S.; Lasse, Aaltonen.; Teemu, S. Interface and control electronics for a bulk micromachined capacitive gyroscope. IEEE Journal of Sensors and Actuators A: Physical. 2008, 147, 183-193.

DOI: 10.1016/j.sna.2008.03.023

[2] Guangjun, Liu.; Anlin, Wang.; Tao, J. A Novel Tuning Fork Vibratory Microgyroscope with Improved Spring Beams. Nano/Micro Engineered and Molecular Systems. 2008, 257-260.

DOI: 10.1109/nems.2008.4484330

[3] Jalpa, S.; Houri, J.; Ajit S. CMOS ASIC for MHz Silicon BAW Gyroscope. IEEE. 2008, 2458-2461.

[4] Ajit, S.; Mohammad, F. Z.; Farrokh, A. A 104-dB Dynamic Range Transimpedance-Based CMOS ASIC for Tuning Fork Microgyroscopes. IEEE journal of solid-state circuits. 2007, 1790-1802.

DOI: 10.1109/jssc.2007.900282

[5] Robert, P. L. Adaptive Mode Tuning for Vibrational Gyroscopes. IEEE transactions on control systems technology. 2003, 242-247.

DOI: 10.1109/tcst.2003.809240

[6] Yen, C.; Chen, R. T. A Control and Signal Processing Integrated Circuit for the JPL-Boeing Micromachined Gyroscopes. IEEE transactions on control systems technology. 2005, 286-300.

DOI: 10.1109/tcst.2004.839558

[7] Lili, D.; Qing, Z.; Zhiqiang, G. A Novel Oscillation Controller for Vibrational MEMS Gyroscopes. American Control Conference. 2007, 3204-3209.

[8] Robert, T.; M'Closkey, A. V. Analysis of a Microsensor Automatic Gain Control Loop. Proceedings of the American Control Conference. 1999, 3307-3311.
