The Finite Element Analysis of Steel Cord in Radial Tire’s Belt Ply

Abstract:

The belt ply plays an important role in the performance of radial tires, and makes the adhesion strength among rubber steel cords of the belt ply become the focus of recently research. This paper focuses on the study of the theoretical analysis of the force on the belt ply, obtaining the relationship between the size of the load at the single steel wire and the outside load and the steel wire’s deformation on a single steel wire. Taking advantage of the software ANSYS Workbench 13.0, we carried out the simulation analysis of the single steel wire, and intuitively showed you the deformation and stress of belt ply’s steel wire under the different forces, providing theoretical basis and reference value for further researches on the adhesion fatigue life of rubber steel wires.

• Periodical: Key Engineering Materials (Volume 501)
• Pages: 495-499
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.501.495
• Online since: January 2012
• Authors: Li Li, Yun Wang
• Keywords: Radial Tire, Steel Cord, Workbench

References

[1] S. Lin: Finite Element Analysis of All-steel Radial Tire[D]. Harbin: Harbin Institute of Technology, 2007. (in Chinese).

[2] Z. Xu, S. G. Zhao: Nonlinear Finite Element Analysis of Radial Tire under Multi-conditions[D]. Qingdao: Qingdao University of Science and Technology, 2009. (in Chinese).

[3] W. Chen, W. Y. Cui: Three-dimensional Finite Element Analysis of All Steel Radial Truck Tire[D]. Beijing: Beijing University of Chemical Technology, 2005. (in Chinese).

[4] G. Y. Pu: ANSYS Workbench 12 of Basic Tutorial and Example Explanation [M]. Beijing: China Water Power Pre0ss, 2010. pp, 72-78.
