Finite Element Analysis of PP-3 Meshing Rotor

Abstract:

PP-3 meshing rotor has been analyzed in strength using the finite element method. The changes of the strain, stress and displacement have been represented by the visual picture, so whether the designed rotor is met the intended designing requirements or not will be known. At the same time, optimization designing is conducted further to the rotor through the analysis of the structure.

• Periodical: Key Engineering Materials (Volume 501)
• Pages: 555-560
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.501.555
• Online since: January 2012
• Authors: Chuan Sheng Wang, Ping Ping Shan, Wei Wei Liu
• Keywords: Boundary Condition, Finite Element, Meshing, PP-3 Meshing Rotor, Pro/E

References

[1] Zhang Hai,Pao Zhoubo,Chen Wei. New physical meaning o rubber mixing power curve .Rubber Industry,1998,45（12）:707-710.

[2] Bian Huiguang,Liu Mingxia,Wang Chansheng. Finite element analysis of four edges synchronous rotor.2006,32（6）:1-6.

[3] Xun Bing. Lifting and Transportation Machinery,2003,（2）:13-15.

[4] Li Zhongtao,Su Xianzheng,Song Qiang. Introducing GK270N mixer machine of the overhaul. Rubber Technology and Equipment,1998,24（4）:42-43.

[5] Wang Xiping,Feng Bo. F270 mixer units of the overhaul and transformation. Rubber Technology and Equipment,1999,25（4）:48-49.

[6] Peng Zhishen. F270 mixer machine overhaul and transformation. Rubber Technology and Equipment,2000,26（3）:42.
