Cazacu and Barlat Criterion Identification Using the Cylindrical Cup Deep Drawing Test and the Coupled Artificial Neural Networks – Genetic Algorithm Method

Abstract:

This paper deals with the identification of the anisotropic parameters using an inverse strategy. In the classical inverse methods, the inverse analysis is generally coupled with a finite element code, which leads to a long computational time. In this work an inverse analysis strategy coupled with an artificial neural network (ANN) model is proposed. This method has the advantage of being faster than the classical one. To test and validate the proposed approach an experimental cylindrical cup deep drawing test is used in order to identify the orthotropic material behaviour. The ANN model is trained by finite element simulations of this experimental test. To reduce the gap between the experimental responses and the numerical ones, the proposed method is coupled with an optimization procedure based on the genetic algorithm (GA) to identify the Cazacu and Barlat’2001 material parameters of a standard mild steel DC06.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 637-642
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.637
• Online since: February 2012
• Authors: Hamdi Aguir, José Luis Alves, Marta C. Oliveira, Luis Filipe Menezes, Hedi BelHadjSalah
• Keywords: Artificial Neural Network (ANN), Cylindrical Cup Deep Drawing Test, Genetic Algorithm (GA), Inverse Identification

References

[1] S. Cooreman, D. Lecompte, H. Sol, J. Vantomme, D. Debruyne, Elasto-plastic material parameter identification by inverse methods: calculation of the sensitivity matrix. Int J Solids Struct (2007);44:4329–41.

DOI: 10.1016/j.ijsolstr.2006.11.024

[2] S. Kucharski, Z. Mróz, Identification of yield stress and plastic hardening parameters from a spherical indentation test. Int. J. Mech. Sci. (2007);49:1238–50.

DOI: 10.1016/j.ijmecsci.2007.03.013

[3] J.F. Duarte, F. Simões, P. Teixeira, A. Santos, Experimental Benchmark#7: Cylindrical cup-earing", Digital Die Design System (3DS), IMS 1999 000051, Communication presented in Inter-Regional Meeting, Paris, (2002).

[4] H. Aguir, J.L. Alves, M.C. Oliveira, L.F. Menezes, H. BelHadjSalah, Material parameters identification using the cylindrical cup deep drawing test and the coupled ANN-inverse method. 7th JSTMM conference, Hammamet, Tunisia, (2010).

DOI: 10.4028/www.scientific.net/kem.504-506.637

[5] O. Cazacu, Fr. Barlat, Application of the theory of representation to describe yielding of anisotropic aluminum alloys. Int. Journal of Engineering Science (2003) ; 41 :1367–1385.

DOI: 10.1016/s0020-7225(03)00037-5

[6] M.C. Oliveira, J.L. Alves, L.F. Menezes, Algorithms and Strategies for Treatment of Large Deformation Frictional Contact in the Numerical Simulation of Deep Drawing Process", Archives of Computational Methods in Engineering (2008);15:113-162.

DOI: 10.1007/s11831-008-9018-x
