An Upper-Bound Prediction of Tangential Force in Single Point Incremental Forming

Abstract:

In the present work, the upper-bound approach is used to study the deformation zone of single point incremental forming of truncated cones. The velocity field and the dissipated power of the process are achieved using an assumed deformation zone and streamlines defined by Bezier curves. The tangential force acting on the tool is attained by optimizing the presented upper-bound solution. Then, influences of the effective parameters including vertical pitch, initial thickness, tool diameter, and wall angle on the tangential force are investigated. In order to validate the presented upper-bound solution, predicted tangential forces are compared with experimental data available in literature. The comparison shows an appropriate agreement between them.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 833-838
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.833
• Online since: February 2012
• Authors: Mohammad Javad Mirnia, Bijan Mollaei Dariani
• Keywords: Deformation Zone, Forming Forces, Single Point Incremental Forming (SPIF), Upper-Bound Approach

References

[1] M.S. Shim, J.J. Park, The formability of aluminum sheet in incremental forming, J. Mater. Process. Technol. 113 (2001) 654-658.

DOI: 10.1016/s0924-0136(01)00679-3

[2] K. Jackson, J. Allwood, The mechanics of incremental sheet forming, J. Mater. Process. Technol. 209 (2009) 1158–1174.

[3] J.M. Allwood, D. R. Shouler, Generalised forming limit diagrams showing increased forming limits with non-planar stress states, Int. J. Plast. 25 (2009) 1207–1230.

DOI: 10.1016/j.ijplas.2008.11.001

[4] P. Eyckens, A. Van Bael, P. Van Houtte, Marciniak–Kuczynski type modelling of the effect of Through-Thickness Shear on the forming limits of sheet metal, Int. J. Plast. 25 (2009) 2249–2268.

DOI: 10.1016/j.ijplas.2009.02.002

[5] F. Micari, G. Ambrogio, L. Filice, Shape and dimensional accuracy in Single Point Incremental Forming: State of the art and future trends, J. Mater. Process. Technol. 191 (2007) 390–395.

DOI: 10.1016/j.jmatprotec.2007.03.066

[6] H.Iseki, An approximate deformation analysis and FEM analysis for the incremental bulging of sheet metal using a spherical roller, J. Mater. Process. Technol. 111 (2001) 150-154.

DOI: 10.1016/s0924-0136(01)00500-3

[7] L. Filice, G. Ambrogio, F. Micari, On-Line Control of Single Point Incremental Forming Operations through Punch Force Monitoring, Ann CIRP 55 (2006) 245-248.

DOI: 10.1016/s0007-8506(07)60408-9

[8] R. Aerens, P. Eyckens, A. Van Bael, J.R. Duflou, Force prediction for single point incremental forming deduced from experimental and FEM observations, Int. J. Adv. Manuf. Technol. 46 (2010) 969–982.

DOI: 10.1007/s00170-009-2160-2

[9] C. Kim, S.Y. Jung, J.C. Choi, A lower upper-bound solution for shear spinning of cones, Int. J. Mech. Sci. 45 (2003) 1893–1911.

DOI: 10.1016/j.ijmecsci.2003.11.002

[10] K. Abrinia, M. J. Mirnia, A new generalized upper-bound solution for the ECAE process, Int. J. Adv. Manuf. Technol. 46 (2010) 411–421.

DOI: 10.1007/s00170-009-2103-y
