Application of Motion Controller on the Fine Milling Machine Tool for the Large Double-Sided of Aluminum Ingot

Abstract:

In view of the processing characteristic of large equipment, The CNC system of the fine milling machine tool for the large double-sided of aluminum ingot is designed, the hardware of the system is introduced, the software is illuminated mainly, the system is configured based on SCOUT, and the control programs of the manual and automatic processing are designed. Based on WINCC Flexible, the operating system which can meet the multi-interface easy to operate and live real-time monitoring is designed. As the result of the commissioning, the system is stable and reliable.
