Lateral Extrusion of A6063 Pipes with a Lost Core of Alumina Powder Bonded with Wax

Abstract:

The authors have developed a lateral extrusion process with a lost core. The outline of the process is as follows. First, the cavity of a pipe, or a channel material, is filled up with liquid of a low-temperature melting material. The low-temperature melting material is then solidified to become a soluble core of the pipe. The authors call this soluble core the lost core. Next, the material is compressed longitudinally as a composite billet and extruded in the lateral direction. After deformation, the low-temperature melting material is melted and removed. The process can performed in a compression state to control the precise appearance of the product. This study examines a new core material, alumina powder (alumina ball) bonded with wax, as a core material. A mixing methodology for wax and alumina powder is discussed along with the effect of their mixing ratio on the deformation of the pipe.

• Periodical: Key Engineering Materials (Volumes 523-524)
• Pages: 1006-1011
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.523-524.1006
• Online since: November 2012
• Authors: Takahiro Ohashi, Ngoquang Thanh, Ryosuke Miyajima
• Keywords: Hollow Product, Lateral Extrusion, Radial Forging, Tube Forming, Tube Hydro-Forming (THF)

References

[1] C.Park, M.Miyagawa, Deformation and fracture of the tube suffering axial compression load and internal pressure No.1, J. Japan Soc. Mech. Eng. Ser I, 32-235(1966) 447–456 (in Japanese).

[2] C.Park, M.Miyagawa, Deformation and fracture of the tube suffering axial compression load and internal pressure No.2, J. Japan Soc. Mech. Eng. Ser I, 32-243(1966) 1661-1667 (in Japanese).

[3] F.C. Lin and S.Y. Lin, Elimination of fold defects in the radial extrusion of tubular components using an elastic support ring., J. Strain Analysis, 38-2(2003) 169–179.

DOI: 10.1243/030932403321163695

[4] S.B. Petersen, J.M.C. Rodriges and P.A.F. Martins, Production of tubular components by radial extrusion –A finite elements analysis, , J. Mater. Proc. Technol., 45(1994)87-92.

[5] S.Rudolf, Hollow lateral extrusion of tubular billets –A newly developed cold forging process, UTF Science, I(2011), online magazine on http://www.utfscience.de/iii-2011/ magzininfo_11 _1703_1_de.html.

[6] Y.Ma, Y.Qin and R.Balendra, Forming of hollow gear-shafts with pressure-assisted injection forging, J. Mater. Proc. Technol., 167(2005)294-301.

DOI: 10.1016/j.jmatprotec.2005.05.053

[7] T. Ohashi　and K. Hayashi, Lateral extrusion of A6063 aluminum alloy pipes with a lost core , J. Mater. Proc. Technol., 138(2003) 560–563.

DOI: 10.1016/s0924-0136(03)00146-8

[8] T. Ohashi, K. Matui, and Y. Saotome, The lateral extrusion of copper pipes with a lost core of low temperature melting alloy, J. Mater. Proc. Technol., 113(2001) 98-102.

DOI: 10.1016/s0924-0136(01)00602-1
