Analysis of Interface Deformation of Steel-Concrete-Steel Sandwich Beam

Abstract:

The effect of the interface slip is neglected in most studies on calculating deflection of sandwich beams. By taking a simply supported sandwich beams under uniformly distributed loads as an example, simplified analytical models of the interface slip are established, and corresponding clculation formulas of interface slip between steel panels and concrete and section curvatures are derived. The formula for deflection of sandwich beams are then presented. This formula reflects the relationship of influence each other between the interface slip and deflection.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 357-360
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.357
• Online since: November 2012
• Authors: Pei Xiu Xia, Guang Ping Zou, Zhong Liang Chang
• Keywords: Deformation, Interface Slip, Steel-Concrete-Steel Sandwich Beam, Theoretical Expression

References

[1] T. M. Roberts, D. N. Edwards, R. Narayanan. Testing and Analysis of Steel-Concrete-Steel Sandwich Beams[J]. J. Construct. Steel Res, 1996, 38(3): 257-279, 2003, 5(4): 5―13.

DOI: 10.1016/0143-974x(96)00022-3

[2] B. McKinley, L.F. Boswell. Behaviour of double skin composite construction[J]. Journal of Constructional Steel Research, 2002, 58 : 1347–1359.

DOI: 10.1016/s0143-974x(02)00015-9

[3] M. Xie, N. Foundoukos, J.C. Chapman. Static tests on steel–concrete–steel sandwich beams[J]. Journal of Constructional Steel Research, 2007, 63: 735–750.

DOI: 10.1016/j.jcsr.2006.08.001

[4] N. Foundoukos, J.C. Chapman. Finite element analysis of steel–concrete–steel sandwich beams[J]. Journal of Constructional Steel Research, 2008, 64: 947–961.

DOI: 10.1016/j.jcsr.2007.10.011

[5] M. Xie, J.C. Chapman. Static and fatigue tensile strength of friction-welded bar–plate connections embedded in concrete[J]. Journal of Constructional Steel Research, 2005, 61: 651–673.

DOI: 10.1016/j.jcsr.2004.10.008

[6] Wang Zuen, Wang Yongxi. Test analysis of the composite of the concrete and the steel plates[J]. Journal of shanghai institute of railway technology, 1995, 16(2): 71-77. (in Chinese).

[7] Xia Zhicheng, Xu Fei, Wang Yongxi. Experiment studies on vertical shear strength of steel-concrete-steel sandwich composite slab[J]. Journal of Harbin university of civil engineering and architecture, 1995, 28(5): 178-185. (in Chinese).

[8] Xie M, Foundoukos N, Chapman JC. Experimental and numerical investigation on the shear behaviour of friction-welded bar–plate connections embedded in concrete[J]. Journal of Constructional Steel Research, 2005, 61: 625–649.

DOI: 10.1016/j.jcsr.2004.10.005

[9] H.D. Wright, T.O.S. Oduyemi. Partial interaction analysis of double skin composite beams[J]. Journal of Constructional Steel Research, 1991, 19(4): 253–283.

DOI: 10.1016/0143-974x(91)90019-w
