Experimental Study on Residual Strength of Panels with Multiple Site Damage

Abstract:

The fatigue test of typical bolt-hole panels with five open holes in a line and the residual strength test of the panels with multiple site crack (MSD) were carried out. The crack initiation life of the test panels and the residual strength of the panels with different MSD crack sizes were obtained by the tests. The application of the net section yield criterion in the determination of residual strength of the panel containing multiple site damage was studied by comparing the calculated results with the test results. The conclusion is that the criterion meets the engineering accuracy requirement in the case of smaller MSD cracked area or smaller MSD crack sizes.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 369-372
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.369
• Online since: November 2012
• Authors: Xiao Zhong Yan, Sheng Nan Wang, Wen Wang
• Keywords: Initiation Life, MSD, Residual Strength, Wing Skin

References

[1] McGuire, J., and Foucault, J., Recommendations for Regulator Action to Prevent Widespread Fatigue Damage in the Commercial Airplane Fleet, Final Rept. of the Airworthiness Assurance Working Group, (1999).

[2] De Wit R, Fields RJ, Low III SR, Harne DE, Foecke T. Fracture Testing of Large-Scale Thin Sheet Aluminium Alloy. NISTIR 5661. US Department of Commerce, 1995. 987).

DOI: 10.6028/nist.ir.5661

[3] Gruber ML, Wilkins KE, Worden RE. Investigations of fuselage structure subject to widespread fatigue damage. In: Bigelow Ceditor. Proceedings from the FAA-NASA Symposium on the Continued Airworthiness of Aircraft Structures. DOT/FAA/AR-97/2. GA, USA, 1996, pp.439-60.

[4] R. Citarella. Non-linear MSD crack growth by DBEM for a riveted aeronautic reinforcement[J]. Advances in Engineering Software. 40 (2009) 253–259.

DOI: 10.1016/j.advengsoft.2008.04.007

[5] R. Citarella, G. Cricrì. A two-parameter model for crack growth simulation by combined FEM–DBEM approach[J]. Advances in Engineering Software. 40 (2009) 363–377.

DOI: 10.1016/j.advengsoft.2008.05.001

[6] Zhang Jianyu, Bao Rui, Zhang Xiang, Binjun FEI. A Probabilistic Estimation Method of Multiple Site Damage Occurrence for Aircraft Structures[J]. Procedia Engineering, 2 (2010) 1115–1124(in Chinese).

DOI: 10.1016/j.proeng.2010.03.120

[7] Ching-long H sua, James Lo a, Jin Yu a, Xiao-gong Lee b, Paul Tan. Residual strength analysis using CTOA criteria for fuselage structures containing multiple site damage. Engineering Fracture Mechanics. 70 (2003) 525–545.

DOI: 10.1016/s0013-7944(02)00135-2

[8] Roberto Galatolo, Karl-Fredrik Nilsson. An experimental and numerical analysis of residual strength of butt-joins panels with multiple site damage. Engineering Fracture Mechanics 68(2001) 1437-1467.

DOI: 10.1016/s0013-7944(01)00027-3

[9] Wang Zhizhi, Chen Li, Nie Xuezhou. Application for Residual Strength Criterion of Multiple Cracks to XX Aircraft. 543-545(in Chinese).

[10] Schijve J. Multiple-site damage in aircraft fuselage structres. Fatigue Fract Engng Mater Struct 1995: 329-44.

[11] Civil aircraft structure durability and damage tolerance design manual[M]. 2002(in Chinese).

[12] Cherry M C , Mall S , Heinemann M B , et al . Residual strength of unstiffened aluminum panels with multiple site damage[J]. Engineering Fracture Mechanics, 1997, 57(6): 7012713.

DOI: 10.1016/s0013-7944(97)00037-4
