Damage Analysis of 2D Woven Composite Laminates Containing an Open-Hole under Tensile Loadings

Abstract:

In order to understand damage mechanism, the influences of lay-up construction of laminates and environgment on tension behavior of 2D woven composite laminates with an open-hole, which was manufactured by a new technology, uniaxial tension tests are performed in 3 different environments on 4 kinds of lay-up specimens, using a WE-50 electromechanical universal material testing machines. The fracture of specimens are analysed through micrographic observations. The result show that there is a large difference both in tensile strength and damage mechanism due to different kinds of lay-up specimens: 1) the tensile strength of specimens that only with ±45 degree laminated is much lower than other samples with different kinds of layup and its tensile stress-strain curves presents nonlinear; 2)The failure modes and damage mechanism determines the strength of specimens; 3)The change of environment had a certain effect on the mechanical behaviors of materials, in this paper, it will cause the tensile strength of speicmens decreasing.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 373-376
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.373
• Online since: November 2012
• Authors: Xiao Qiong Zhang, Wei Guo Guo, De Shuan Kong
• Keywords: Damage Analysis, Failure Model, Open-Hole Tension, Woven Composite

References

[1] L.W. Chang, S.S. Yau and T.W. Chou: Comp. Vol. 18 (1987), p.233.

[2] H.J. Lin, Y.J. Lee: Comp. Struct. Vol. 21 (1992), p.155.

[3] P.A. Lagace: Comp. Sci. Technol. Vol. 26 (1986), p.95.

[4] M.T. Kortschot, P.W.R. Beaumont: Comp. Sci. Technol. Vol. 39 (1990), p.303.

[5] C. Schuecker, H.E. Pettermann: Comp. Struct. Vol. 76 (2006), p.162.

[6] C. Schuecker, H.E. Pettermann: Comp. Struct. Vol. 86 (2008), p.908.

[7] T. Flatscher, C. Schuecker and H.E. Pettermann: Int. J. Fract. Vol. 158 (2009), p.145.

[8] C. Schuecker, H.E. Pettermann: Arch. Comput. Methods. Eng. Vol. 15 (2008), p.163.

[9] I. Lapczyk, J.A. Hurtado: Comp. Part A. Vol. 38 (2007), p.2333.
