Prediction of Springback of the One-Axle Rotary Shaping Based on Artificial Neural Network

Abstract:

One-axle rotary shaping with the elastic medium (RSEM) is a kind of advanced sheet metal forming process. The research object is the springback of aluminous U-section. The orthogonal method is used to arrange the simulation experiments, the forming and springback of the workpiece are simulated successfully with the Finite Element Simulation software, and The main factors influenced the RSEM are analyzed. The simulation results are used as the training samples of the artificial neural network (ANN), and the ANN prediction model of RSEM process is set up. The prediction results would be tested with the experiment data, and only a little tolerance was existed between the two values. It demonstrated that the combination of orthogonal test, numerical simulation and neural network could effectively predict the springback of RSEM, the design efficiency of process parameters would be improved. It would guide the development of precision forming technology.

• Periodical: Key Engineering Materials (Volumes 535-536)
• Pages: 318-321
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.535-536.318
• Online since: January 2013
• Authors: Xia Jin, Shi Hong Lu
• Keywords: Finite Element (FE) Simulation, Neural Network (NN), One-Axle Rotary Shaping, Prediction, Springback

References

[1] J. Yan, Z.D. Wen, M. Wang, FEM Analysis of Two-Axle Bending Technique, Mechanical Science and Technology, 22(2003)203-205

[2] FECIT Sci-Tech Product R&D Center , Neural Network Theory and MATLAB7, Electronic Industry Press, Beijing, (2005)

[3] M. Inamdar, Development of an artificial neural network to predict springback in air vee bending, The International Journal of Advanced Manufacturing Technology, 16(2000)376-381

DOI: 10.1007/s001700050169

[4] R. Hambli, F. Guerin, Application of a neural network for optimum clearance prediction in sheet metal blanking processes, Finite Elements in Analysis and Design, 39(2003)1039-1052

DOI: 10.1016/s0168-874x(02)00155-5

[5] G.M. Lu, Numerical Simulation and Springback Prediction of Stamping in the U-shaped Auto Body Panel, Yangzhou University, Yangzhou, (2004)

[6] B.Zhang, D.S.Li, X.B. Zhou, Springback Prediction of Stretch Forming Based on Artificial Neural Network, J. of Plasticity Eng. , 10(2003)28-31

[7] H.C. Kwon, Y.T.Im, D.C. Ji．The Bending of An Aluminum Structural Frame with a Rubber Pad, J. Mater. Process Technol, 113 (2001) 786~791

[8] J.J. Sun, Single-axle roll-bending research and finite element analysis of the U-profile, Nanjing University of Aeronautics and Astronautics, Nanjing, (2008)
