Study on the Control System of Area-Contact Magnetorheological Finishing Machine

Abstract:

To achieve the goal of processing large diameter and ultra-smooth optical components, the control system of the area-contact magnetorheological finishing machine is introduced. The system includes motion control systems, structural adjustment systems, detection systems and alarm systems. PLC, the core of the system, is used to data collection, input and output control, process control and so on. The touch screen as the man-machine interface is simple and intuitive, easily to operate. This paper describes the algorithms of this control system and introduces the design of the hardware and software of the system. This control system have a stability performance, strong anti-interference ability. The result shows that the magnetorheological finishing machine could processφ300mm optical components the optical components, radius range of optical components is -∞≤R-30 or 30≤R≤∞, and the surface roughness less than 1nm.

• Periodical: Key Engineering Materials (Volume 552)
• Pages: 234-237
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.552.234
• Online since: May 2013
• Authors: Zhi Li Chen, Yong Gang An, Zhao Shi Zhang
• Keywords: Control System, Magnetorheological Finishing (MRF), Programmable Logical Control (PLC), Touch Screen

References

[1] Wang Wei. Research on methods of area-contact magnetorheological finishing [master degree thesis] [D].optic-electronic engineering department, Xi'an Technological University,2007.

[2] Ioannides M G., Design and implementation of PLC-based monitoring control system for induction motor [J], IEEE Transactions on Energy Conversion, 2004,19 (3) :469 – 476.

DOI: 10.1109/tec.2003.822303

[3] Zhang Feng, Zhang Xuejun, Se Jingchi, etc.establishment of mathmatic mode for Magnetorheological polishing technology[J] .Optical Technology , 2000, 26(2)：190-192.

[4] Aoki T, Hashiyama T, Zanma T, et al, Automatic generation of motion sequence in programmable logical control [J], 6th International Workshop on Advanced Motion

DOI: 10.1109/amc.2000.862912

[5] Rock P, Bauman T, Granzin B, PLC-Based Turbine Governor System [J], Conference Record of Annual Pulp and Paper Industry Technical Conference, 2006:1–3.

DOI: 10.1109/papcon.2006.1673776

[6] Xue Yingcheng. PLC and touch screen control technology [M].Peking; Chinese electronic power press, 2008.50-83.

[7] A. B. Shorey. Mechanisms of the Material Removal in Magnetorheological Finishing (MRF) of Glass. PH. D Dissertation of University of Rochester, 2000.
