The Static Tester of Fire Control System Performance Parameters

Abstract:

This tester is mainly used to test the firepower of armored vehicles weapon equipment, the artillery loosening amount and rigidity of fire control system, the largest mobilization artillery speed and other related static parameters. In this paper, the design of the tester include: static parameters optical probe, the vehicle central control device, the image processing device, the test target and so on. In the static parameter tests of weapon systems, the static probe is installed in the muzzle, the prescriptive force is imposed on the artillery tube to produce movement, CCD camera can photography the relative motion image of the target, then the computer processes images according to the corresponding program, and figures out the trajectory of the artillery tube, thus the corresponding static parameters is calculated. Experimental results show that: The system has reached a very good image quality, and the reliability is very high, Diagonal field of view>4°, the specification requirements are reached.

• Periodical: Key Engineering Materials (Volume 552)
• Pages: 319-324
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.552.319
• Online since: May 2013
• Authors: Chun Yan Wang, Hao Sun, Tao Li
• Keywords: Fire Control System, Measurement Methods, Mobilization Artillery Speed, Static Parameters

References

[1] Chunyan Wang, Huilin Jiang, Lu Wang, Xiaoman Wang, Zhijian Wang: Multi-axis Optical System for Fire Control Dynamic Performance Testing[J]. ACTA ARMAMENTARII Vol. 32 (2011), No.6:745~751

[2] Chunyan Wang, Meijuan Wang, Qingcai Zhou, Lu Wang, Zhikang Bao: Real-time Test System Design of Long –range Target[J]. APPLIED OPTICS Vol.32 (2011), No.4：709～713

[3] Chunyan Wang, Shuai Li, Jilin Yuan etc. Repeated Aiming Precision Measurement System Design[J]. Changchun University of Technology Journal. Vol.33 (2010), No.2：28～31

[4] Chi He, Keding Zhao, Sanren Feng, Hongguang Xu, Youhe Han: Research on gun control system static parameter test and key technology[J]. Nanjing University of Science and Technology Journal Vol.28 (2004), No.1：14～18

[5] National Military Standard. GJB1543-92: Acceptance Rules of Military optical instruments. The Commission of Science.( 1993-06-01)

[6] Yang Han, Tianqing Chang, Shiyong Ding: Modeling and Dynamic Characteristic Analysis of Semi-autonomous Fire Control System[J]. Computer Engineering and Design. Vol.32 (2011), No.12：4155～4168

[7] Wuyun Yao, Deyou Xu: Detection System of A Certain Type of self-propelled artillery fire control system[J]. Weaponry Industry Automation. Vol.29 (2010), No.12：69～72

[8] Jin Duan, Xiaoman Wang, Zhijian Wang, Huilin Jiang: Dynamic Parameter Measurement of Fire Control System[J]. Fire and Command Control. Vol.36 (2011), No.11：200～202
