Error Analysis of Optical Alignment Based on Multi-Beam Splitting

Abstract:

Beam splitter is widely applied in many optical systems. The beam splitter is generally composed of many reflective mirrors and beam splitting prisms. The optical components can not reach the theoretical design state during assemble process. It must be solved through optical alignment. The mathematics model of alignment and error analysis for beam splitter are built in this paper. The effect of optical alignment error of beam splitter on optical system could be analyzed with this mathematical model. At the mean time, the mechanical alignment of beam splitter is directed to fast alignment in practical process. One kind of optical communication system is shown as example. The optical transmitting exit is commonly used. The requirement of axis parallelism of sub-systems is very strict. The axis parallelism between sub-systems reaches 5’’ in experiment with this model application.

• Periodical: Key Engineering Materials (Volume 552)
• Pages: 329-335
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.552.329
• Online since: May 2013
• Authors: Lei Zhang, Zhuo Lin Li, Zhi Ying Liu
• Keywords: Axis Parallelism, Beam Splitter, Optical Alignment, Optical Communication

References

[1] FANG Jing-yue,ZHANG Hai-liang,JIA Hong-hui, et al. Optical antenna for non-line-of-sight scattering atmospheric optical communication.Journal of Applied Optics.Vol.29(2008),P98~102

[2] CHEN Jian-wen,YAO Ya-feng, LIU Zi-li, et al. Design and realization for space optical communication system. Opto-electronic Engineering,Vol.9(2004),P14~17

[3] HOU Rui,ZHAO Shang-hong,LI Yong-jun, et al. Analysis of space environment effects on satellite optical communication system. Optical Communication Technology，Vol.4(2008),P61~64

[4] CAO Yang,AI Yong,LI Ming, et al. Ground simulation experiment of fine tracking for spatial optical communication. Journal of Optoelectronics.Laser, Journal of Applied Optics，Vol.51(2009)，P35~39

[5] Zheng yang,Yu Ling,He Wenjun, et al.Research on optical structure of liquid optics directional compensation.Journal of Dalian University of Technology,Vol.51(2011),P45~46

[6] Zhang Lei,He Wenjun,Zheng Jianping et al.Error analysis for optical alignment of beam splitters in optical communication.Journal of Applied Optics,Vol.33(2012),P226~228

[7] Zheng Lei,Zheng Yang,He Wenjun,et al. Research on automatic directional benchmark based on liquid optical compensation.Journal of applied optics.Journal of Applied Optics,Vol.32(2011),P1055~1056
