Influence of Superimposing of Oscillation on Sheet-Bulk Metal Forming

Abstract:

Due to novel processes like sheet-bulk metal forming, the requirements for sheet metal forming are increased. Sheet-bulk metal forming is a new interconnected process in which the part itself is manufactured by deep drawing and the gearing will be produced with bulk forming in a combined process at room temperature. This process is characterized by a triaxial state of stress and a triaxial dimensional change with true strains up to  = 1-2 by using sheet blanks. Within the use of superimposing of oscillation on a sheet-bulk metal forming process the required forming force can be reduced and the accuracy of dimension of the part can be improved. Within this paper the influence of the superimposing of oscillation on the sheet bulk metal forming will be shown on combined ironing and external extrusion process. For the superimposing of oscillation different excitation frequencies will be analysed. Furthermore the die clearance will be varied to increase the requirements on the process. Finally the influence of the different excitation frequencies and the different die clearances will be summarized in cause and effect relationship diagram.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1484-1489
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1484
• Online since: June 2013
• Authors: Bernd-Arno Behrens, Sven Hübner, Milan Vucetic
• Keywords: Sheet-Bulk Metal Forming, Superimposing of Oscillation

References

[1] M. Merklein, J.M. Allwood, B.-A. Behrens, A. Brosius, H. Hagenah, K. Kuzman, K. Mori, A. E. Tekkaya, A. Weckenmann, , 2012, Bulk forming of sheet metal, CIRP Annals - Manufacturing Technology, 59/2.

DOI: 10.1016/j.bbr.2011.03.031

[2] M. Werbs, A. Bawohl, L. Gerlach: Kostengünstige Herstellung verzahnter Bauteile durch Blechmassivumformung, Tagungsband zum 1. Erlanger Workshop Blechmassivumformung, Bamberg: Meisenbach, 2011, pp.2-14.

[3] A. Weckenmann, B.-A. Behrens, E. Reithmeier, G. Akkasoglu, M. Vucetic, T. Cahyono, C. Ohrt, S. Hübner, M. Kästner, Appliance of the matury method in the development of endoscopic geometry inspection for sheet bulk metal forming tools, in: Total Quality Management & Excellence 39 (2011) 1, Belgrade, 99 11-16.

[4] M. Merklein, Manufacturing of complex functional components with variants by using a new sheet-metal forming process, Proceedings of the 42th International Cold Forging Group ICFG, Shnaghai, 2009, pp.143-155.

[5] B.-A. Behrens, S. Hübner, M. Vucetic, Shortening the process chain by sheet-bulk metal forming processes, Proceedings of the 10th Global Conference on Sustainable Manufacturing, Istanbul 2012, pp.64-68.

[6] A. Schwager, Contribution to the influence of superposed energy forms on the yield strength of metallic materials (in German language), PhD thesis, TH Karl-Marx-Stadt, 1975.

[7] J. Ulmer, Contribution to the calculation of reduced friction force for the ultrasound superposed strip drawing test (in German language), Beiträge zur Umformtechnik Band 37, PhD thesis, IFU, Univ. Stuttgart, 2003.

[8] B.-A. Behrens, A. Bouguecha, T. Cahyono, S. Hübner, R. Krimm, T. Matthias, V. Salfeld, K. Voges-Schwieger, M. Vucetic, Blechmassivumformung – ein neues Verfahren zur Herstellung komplexer Bauteile, Tagungsbeitrag 20. Umformtechnisches Kolloquium Hannover 2011 "Umformtechnik – Innovationen aus Industrie und Wissenschaft", ISBN 978-3-00-033656-0, pp.161-172.

[9] B.-A. Behrens, S. Hübner, R. Krimm, C. Wager, M. Vucetic, T. Cahyono, Development of a Hydraulic Actuator to Superimpose Oscillation in Metal-Forming Presses, Key Engineering Materials, 473 (2011), S. 217-222.

DOI: 10.4028/www.scientific.net/kem.473.217
