Experimental Investigation on the Cutting Heat Distribution with Different Coating Structures Inserts

Abstract:

It is known that carbide inserts have better cutting performance. Coating structures will affect the inserts’ life and the cutting heat distribution on chip, workpiece and insert. In this manuscript, three kinds of turning inserts with different coating structures were used to test under the same cutting conditions and inserts geometry for cutting AISI1045 quenched and tempered steel. These coating structures are CVD-TiCN/Al₂O₃/TiN, PVD- TiAlN, CVD-TiCN/Al₂O₃. The chip temperature and the cutting force are measured by the infrared thermal image and cutting force instrument. Total heat includes the chip heat and the dissipated heat which is calculated using the formula deduced. The coefficient η of cutting heat flow of chip and the influence of coating structures on cutting heat distribution are investigated. The results show that the three kinds of turning insert with different coating structures have different effect on cutting heat distribution and the PVD- TiAlN coating performs better for taking away more heat on chip when turning AISI1045 quenched and tempered steel.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 1953-1960
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.1953
• Online since: June 2013
• Authors: Yun He, Lin Ning Li, Cheng Yao Li, Long Chen, Xin Yue
• Keywords: Carbide Turning Inserts, Coating Structure, Cutting Heat Distribution

References

[1] Rech J．Influence of cutting inserts coatings on the tribological phenomena at the Inserts-chip interface in orthogonal dry turning[J]．Surface and Coatings Technology．2006，200,5132-5139．

DOI: 10.1016/j.surfcoat.2005.05.032

[2] Grzesik W，Bartoszuk M，Nieslony P．Finite element modelling of temperature distribution in the cutting zone in turning processes with differently coated inserts[J]．Journal of Materials Processing Technology．2005，164-165：1204-1211．

DOI: 10.1016/j.jmatprotec.2005.02.136

[3] Li, Kuan-Ming , Liang, Steven Y. Modeling of cutting temperature in near dry machining. Journal of Manufacturing Science and Engineering, Transactions of the ASME. 2006,128,416-424

DOI: 10.1115/1.2162907

[4] Akbar, F. Mativenga, P.T, Sheikh, M.A. On the heat partition properties of (Ti, Al)N compared with TiN coating in high-speed machining. Proceedings of the Institution of Mechanical Engineers, Part B: Journal of Engineering Manufacture.2009,223,363-375.

DOI: 10.1243/09544054jem1365

[5] Grzesik, W. Influence of thin hard coatings on frictional behaviour in the orthogonal cutting process, Tribology International. 2000,33,131-140

DOI: 10.1016/s0301-679x(00)00072-4

[6] R. M'Saoubi, H. Chandrasekaran, Investigation of the effects of inserts micro-geometry and coating on inserts temperature during orthogonal turning of quenched and tempered steel, Int. J. Mach. Inserts Manuf. 44 (2004) 213–224.

DOI: 10.1016/j.ijmachtools.2003.10.006
