Acoustic Emission for Tank Bottom Monitoring

Abstract:

Acoustic Emission (AE) monitoring is an effective tool for prioritising more conventional non-destructive inspections of above ground tanks, either process or storage vessels. Results obtained from AE monitoring may be assessed against an existing data bank permitting plant management to prioritise maintenance to tanks with high active corrosion rates or leaks. AE results may be used to extend inspection periods of tanks without leaks or active corrosion.This paper briefly covers the theory of AE leak detection and corrosion monitoring including some background research into the difference between AE from corrosion and leaks. It looks at the equipment used and provides a summary of tank test results conducted by ATTAR and other overseas organisations as well as reviewing AE tank inspection economics.

• Periodical: Key Engineering Materials (Volume 558)
• Pages: 445-455
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.558.445
• Online since: June 2013
• Authors: Gary Martin
• Keywords: Acoustic Emission (AE), Corrosion Monitoring, Leaks, Storage Tank

References

[1] Nondestructive Testing Handbook, 2nd Ed., Acoustic Emission Testing, ASNT, Columbus OH, USA, 1987.

[2] API Std 653, Tank Inspection, Repair, Alteration, and Reconstruction, Third Edition, Dec- 2001 American Petroleum Institute

[3] S. Yuyama, "Fundamental Aspects of Acoustic Emission Applications to the Problems Caused by Corrosion," in Corrosion Monitoring in Industrial Plants Using Nondestructive Testing and Electrochemical Methods, ASTM STP 908, Eds G.C. Moran and P. Labine (Philadelphia, PA) pp.43-74, (1986)

DOI: 10.1520/stp17436s

[4] Yuyama, S, et al, Verification of Acoustic Emission Testing of Floor Conditions in Aboveground Tanks by Comparison of Acoustic Emission Data and Floor Scan Testing, Materials Evaluation, Sept, 2007, 929 – 934.

[5] Miinshiou Huang, Liang Jiang, Peter K. Liaw,Charlie R. Brooks, Rodger Seeley, Dwaine L. Klarstrom, "Using Acoustic Emission in Fatigue and Fracture Materials Research", http://www.tms.org/pubs/journals/JOM/9811/Huang/Huang-9811.html.

[6] Rong S Geng,, "Corrosion-related Acoustic Emission and Its Identification" http://www.ndt.net/article/apcndt01/papers/1143/1143.htm

[7] C.M. Nickolaus, Acoustic Emission Monitoring of Above-Ground Storage Tanks", Materials Evaluation, Volume 46, March 1988, pp.508-512

[8] Neilson, A. Acoustic Emission Source Based on a Pencil Lead Breaking. Report 80.15, Danish Weld Inst, Denmark.

[9] Van De Loo, P.J., Herrmann, B., How Reliable is Acoustic Emission (AE) Tank Testing? The Quantified Results of an AE Usergroup Correlation Study! Proceedings of 7th European Conference on Non-Destructive Testing, 1988.
