Dynamically Reconfigurable Multivariable MEMS Sensor Array for Unattended Systems

Abstract:

This paper presents a dynamically reconfigurable multivariable Micro-Electro-Mechanical Systems (MEMS) sensor array, capable of reconfiguration in real time, to meet the sensing demands of unattended systems operating in highly variable environments, with an emphasis on maintaining operation of these systems in the presence of structural damage. This array is comprised of multiple instances of identical sensors which can be dynamically reconfigured to target a variety of measurands including acceleration, rotational rate, magnetic fields, temperature, air pressure and density. A simulated environment is used to illustrate how the array can be dynamically reconfigured to respond to variations in several of these parameters. Also shown are simulations that demonstrate the ability of such a sensor array to continue operation in the presence of structural damage.

• Periodical: Key Engineering Materials (Volume 558)
• Pages: 456-464
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.558.456
• Online since: June 2013
• Authors: Stephen van der Velden, Ian Powlesland, Steve C. Galea, Jugdutt Singh
• Keywords: Array, MEMS, Reconfigurable, Sensor, Structural Health Monitoring (SHM), UAV

References

[1] van der Velden S. P., Powlesland I. G., and Singh J, A Proposed Robust Distributed Control System Architecture For Mini/Micro UAVs, AIAC12 - Twelfth Australian International Aerospace Congress, 2nd Australasian Unmanned Air Vehicles Conference, Melbourne, Australia, 19 - 22 March (2007).

[2] van der Velden S. P. and Powlesland I. G., Interconnecting a flexible sensing array, 2nd Asia-Pacific Workshop on Structural Health Monitoring, Melbourne, Australia, (2008).

[3] Trimmer W. and Stroud R.H., MEMS Overview, The Aerospace Corporation (Adapted from the CRC Handbook), (2006).

[4] Carver R., Calibrate accelerometers for industrial apps, EE Times-Asia, Mar (2008).

[5] Piyabongkarn D., Rajamani R., Greminger M., The Development of a MEMS Gyroscope for Absolute Angle Measurement, IEEE Transactions On Control Systems Technology, vol. 13, No. 2, Mar (2005).

DOI: 10.1109/tcst.2004.839568

[6] Amarasinghe, R.; Dao, D.V.; Toriyama, T.; Sugiyama, S., A silicon micromachined sixdegree of freedom piezoresistive accelerometer, Sensors, 2004. Proceedings of IEEE, vol. 2, pp.852-855, 24-27 Oct. (2004).

DOI: 10.1109/icsens.2004.1426304

[7] Cho J.; Kim K.; An S.; Park H.; Hahm G., A Micromachined Magnetometer-Accelerometer for Navigation Systems, Nano- and Microtechnology: Materials, processes, Packaging, and Systems. Proceedings of SPIE, vol 4936, pp.293-301, (2002).

DOI: 10.1117/12.469429

[8] Jha C. M., Bahl G., Melamud R., Chandorkar S. A., Hopcroft M. A., Kim B., Agarwal M., Salvia J., Mehta H. and Kenny T. W., CMOS-Compatible Dual-Resonator MEMS Temperature Sensor with Milli-Degree Accuracy, Transducers, Lyon France, (2007).

DOI: 10.1109/sensor.2007.4300111

[9] van der Velden S. P., and Singh J., Reconfigurable multivariable MEMS sensor array, in Fifth IEEE International Symposium on Electronic Design, Test and Applications, Ho Chi Minh City, Vietnam, 2010, pp.325-329.

DOI: 10.1109/delta.2010.47

[10] M. Engelhardt, LTspice/SwitcherCAD III, 2008, Linear Technology Corporation, www. linear. com.

[11] Thom T., Aeroplane General Knowledge and Aerodynamics for private and commercial pilots licences, Aviation Theory Centre, (2000).
