Electrohydrodynamic Direct Writing Platform Based on Near-Field Electrospinning

Abstract:

Electrohydrodynamic Direct Writing (EDW) based on Near-Field Electrospinning (NFES) is a novel method to fabricate aligned micro/nano structure. In this article, linear motors and PIV&F servo control algorithm are introduced to set up an EDW experiment platform, by which patterned micro/nano structure can be direct-written. The motion track and position of collector is adjusted accurately by the platform, thus the deposition position and pattern of direct-written micro/nano structure can be controlled according to the pre-designed pattern. When motion velocity of collector higher than the ejection jet, micro/nano structure in straight line can be gained; but twisted structure can be direct-written under lower motion velocity of collector. The standstill of collector is introduced to overcome the pattern distortion that stems from the sharp change of collector motion track and the inertia of following jet. With the help of motion standstill, the patterned micro/nano structure without distortion can be direct-written, and more jet would be deposited at the corner of the pattern leaded to coiled structure. The EHD platform builds up the based for the industrial application of 1D micro/nano structure.

• Periodical: Key Engineering Materials (Volumes 562-565)
• Pages: 614-619
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.562-565.614
• Online since: July 2013
• Authors: Jin Wei, Jian Yi Zheng, Gao Feng Zheng, Yi Hong Lin, Guang Qi He, Hai Yan Liu, Dao Heng Sun, Juan Liu
• Keywords: Electrohydrodynamic Direct Writing, Near-Field Electrospinning, One-Dimension Micro/Nano Structure, Three-Axis Motion Platform

References

[1] D. Li, J. T. McCann, Y. N. Xia, Electrospinning: A simple and technique for producing ceramic nanofibers and nanotubes, J. Am. Ceram. Soc. 89 (2006) 1861-1869

DOI: 10.1111/j.1551-2916.2006.00989.x

[2] A. L. Yarin, S. Koombhongse, D. H. Reneker, Bending instability in electrospinning of nanofibers, J. Appl. Phys. 89 (2001) 4836-4846.

DOI: 10.1063/1.1333035

[3] D. H. Sun, C. Chang, S. Li, L. W. Lin, Near-Field Electrospinning, Nano Lett. 6 (2006) 839-842.

DOI: 10.1021/nl0602701

[4] G. F. Zheng, L. Y. Wang, D. H. Sun, Micro/Nano-Structure Direct-Write Technology Based on Near-Field Electrospinning, Nanotechnology and Precision Engineering, 6 (2008) 20-23.

[5] G. F. Zheng, Y. H. Dai, L. Y. Wang, D. H. Sun. Direct-Write Micro/Nano-Structure For Flexible Electronic Manufacturing. 7th IEEE Conference on Nanotechnology, Hong kong, China, (2007) 795-798.

DOI: 10.1109/nano.2007.4601304

[6] B. L. Zhang, Y. J. Chen, Z. Y. Li, A High Velocity Feed Unit Driven by Linear Motor, Chinese Journal of Mechanical Engineering, 4 (2000) 266-272.

[7] Z. M. Lin, B. Yao, J. J. Ye, G. F. Zheng, The Study of Automatic Programming System for Near-field Electrospinning Direct Write, Adv. Mater. Res. 197 (2011) 3-7.

DOI: 10.4028/www.scientific.net/amr.197-198.3
