Synthetic Aperture Focusing Technique for Detecting Transverse Cracks in Austenitic and Dissimilar Welds

Abstract:

The inspection of austenitic and dissimilar welds using ultrasound demands for sophisticated testing techniques. The application of reconstruction methods like the Synthetic Aperture Focusing Technique (SAFT) on the measurement results provides an appropriate approach for defect characterization and sizing. Nevertheless, the reconstruction algorithm has to consider the aniso-tropic wave propagation inside the inhomogeneous weld material. In recent years the detection of transverse cracks has become increasingly important for ensuring the structural integrity of pipes in the primary circuit of nuclear power plants or longitudinally welded, cladded pipes. However, relia-ble inspection techniques are hardly available. In this particular case, it is expected that the compar-atively long propagation path of the ultrasonic wave field inside the inhomogeneous weld material enhances the effect of anisotropy and influences the accuracy and the signal-to-noise-ratio of the reconstruction result. In this contribution we suggest an advanced ultrasonic testing technique for detecting and sizing of transversal cracks in austenitic and dissimilar welds. The method applies a SAFT reconstruction algorithm considering the anisotropy and the inhomogeneity. A V-arrangement of the transducers in pitch-catch technique is chosen to avoid a direct coupling on the weld face. The reconstruction algo-rithm is based on an extended 3-dimensional weld model and uses a ray-tracing approach for de-termining the wave propagation paths. Along with the reconstruction algorithm the transducer set-up and experimental results of different specimens with artificial transverse flaws are presented. The availability of the proposed method for crack sizing is assessed in comparison to conventional testing techniques.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 1036-1043
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.1036
• Online since: July 2013
• Authors: Jens Prager, Christian Höhne, Mehbub Ur Rahman
• Keywords: Anisotropic Material, Damage Assessment, Synthetic Aperture Focusing Technique (SAFT), Ultrasonic Non-Destructive Evaluation

References

[1] W. Müller, V. Schmitz, G. Schäfer, Reconstruction by the synthetic aperture focussing technique (SAFT), Nucl. Eng. Des. 94 (1986) 393–404.

DOI: 10.1016/0029-5493(86)90022-1

[2] M. Spies, W. Jager, Synthetic aperture focusing for defect reconstruction in anisotropic media, Ultrasonics 41 (2003) 125–131.

DOI: 10.1016/s0041-624x(02)00407-9

[3] A. Shlivinski, K.J. Langenberg, Defect imaging with elastic waves in inhomogeneous-anisotropic materials with composite geometries. Ultrasonics 46 (2007) 89–104.

DOI: 10.1016/j.ultras.2006.04.005

[4] A.E. Bazulin, E.G. Bazulin, D.A. Koval, Application of the TANDEM scheme for reconstructing flaw images by the SAFT method, Russ. J. Nondestruct. Test. 45(7) (2009) 452–463.

DOI: 10.1134/s1061830909070031

[5] J.A. Ogilvy, A layered media model for ray propagation in anisotropic inhomogeneous materials. Appl. Math. Model. 14 (1990) 237–247.

DOI: 10.1016/0307-904x(90)90014-v

[6] S. Kolkoori, M.U. Rahman, J. Prager, Effect of columnar grain orientation on ultrasonic plane wave energy reflection and transmission behaviour in anisotropic austenitic weld materials, J. Nondestruct. Eval. 31(3) (2012) 253–269.

DOI: 10.1007/s10921-012-0140-1

[7] J. Moysan, A. Apfel, G. Corneloup, B. Chassignole, Modelling the grain orientation of austenitic stainless steel multipass welds to improve ultrasonic assessment of structural integrity, Int. J. Press. Vessels Piping 80 (2003) 77–85.

DOI: 10.1016/s0308-0161(03)00024-3

[8] C. Höhne, S. Kolkoori, M.U. Rahman, R. Boehm, J. Prager, SAFT Imaging of Transverse Cracks in Austenitic and Dissimilar Welds, J. Nondestruct. Eval. (2012) DOI 10. 1007/s10921-012-0159-3.

DOI: 10.1007/s10921-012-0159-3

[9] S.I. Rokhlin, T.K. Bolland, L. Adler, Reflection and refraction of elastic waves on a plane interface between two generally anisotropic media. J. Acoust. Soc. Am. 79(4) (1986), 906–918.

DOI: 10.1121/1.393764

[10] A. Chahbaz, R. Sicard, Comparative Evaluation Between Ultrasonic Phased Array And Synthetic Aperture Focusing Techniques, Review of Quantitative Nondestructive Evaluation: Vol. 22, American Institute of Physics (AIP) Conference Proceedings, 657 (2003).

DOI: 10.1063/1.1570213
