Research on the Online Test of the Fly Cutting Machine Tool Spindle

Abstract:

The online test system of the vertical spindle motion error of the ultra-precision fly cutting machine tool was established. And then using the online test system established to test and analyze the state of the rotary motion of the spindle under the idling condition. The axial synchronous motion error value of the spindle under 390rpm is about 61 nm, and the asynchronous error motion is about 33nm. The radial error motion value is about 91nm, and the asynchronous error is about 35nm. Through the test, we found that the axial and radial spindle error motion accuracy under idling speed can been improved with the spindle speed increases.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 177-180
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.177
• Online since: September 2013
• Authors: Peng Qiang Fu, Yong Zhang, Fei Hu Zhang, Jing He Wang
• Keywords: Dynamic Testing, Fly Cutting Machine Tool, Online Testing, Spindle Rotation Error Motion

References

[1] M. Eric, C. Jeremiah and V. Ryan: Techniques Transactions of the ASME, VoL. 2 (2006), pp.180-187.

[2] L.S. Wu, Y. Yang and D.S. Zhou: Machinery Design & Manufacture, (2009) No. 1, pp.107-109.

[3] W. Gao, T. Makoto, A. Takeshi, et al.: Precision Engineering. Vol. 31 (2007), pp.310-316.

[4] Y.L. Xiong: Mathematic Methods of the Precision Measurement. (Chinese Measuring Press, China 1989).

[5] C.H. Liu: Measurement Science and Technology, (2004) No. 9, pp.1733-1741.

[6] J.E. Tu, B. Bossmanns, S.C.C. Hung: Precision Engneermg, Vol. 21, (1997) No. (2-3), pp.90-101.

[7] C.H. An, Y. Zhang, Q. Xu, et al.: International Journal of Machine Tool & Manufacture, Vol. 50 (2010), pp.374-385.
