The Development of NC Tenoning Machine's Control System Based on HUST Controller

Abstract:

This paper is to solve the problems existed in the traditional tenoning, such as the poor flexibility, low accuracy, low efficiency, high labor intensity and so on. The HUST controller can provide multiple interfaces to connect various peripheral devices, and it is with the embedded PLC, multiple execution mode and control function, self-diagnosis and error prompt. So, the NC Tenoning Machines Control system based on the HUST H2 controller can automatically machine multiple tenons, including cross waist round tenon, vertical waist round tenon, round tenon, square tenon.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 498-502
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.498
• Online since: September 2013
• Authors: Jian Hua Tao, Bin Chen, Xiao Jun Fei, Hua Liu, You Wen Bao
• Keywords: Control System, Embedded PLC, HUST Controller, NC Tenoning Machine

References

[1] Y. Ma: Wood Industry, Vol. 18 (2004) No. 1, pp.5-8.

[2] Z.X. Zhou: Journal of Inner Mongolia Agricultural University, Vol. 28(2007) No. 4, pp.200-203.

[3] N. Valentin. Imprimeria Oltenia, 1987: 187-196.

[4] N. Wang: Forest Product Industry, Vol. 35(2008) No. 2, pp.37-39.

[5] Y.X. Zhang: Journal of Tianjin Vocational University, Vol. 15(2006) No. 4, pp.48-50.

[6] Wiring Handbook of HUST H4 CNC Machine (Hundred Million Industrial Co., LTD, 2006). (In Chinese).
