Structural Design and Analysis of the New Mobile Refuge Chamber

Abstract:

At present, the mobile refuge chambers are mostly used square or circular structures. Based on these researches, a new chamber structure is presented in this paper, which is square and circular combined structure. The size and connection way are designed through the analysis of the working conditions and the requirements of the installation, transportation, maintenance and so on. Then the new structure is simplified to four kinds of cabin model, which can be analyzed by the ANSYS software. By the simulation analysis the reliability of the new structure is determined, which provides a theoretical basis for guiding the structural design of the mobile refuge chamber.

• Periodical: Key Engineering Materials (Volume 584)
• Pages: 175-178
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.584.175
• Online since: September 2013
• Authors: De Gong Chang, Chen Shao, Song Mei Li, Min Min Du
• Keywords: ANSYS, Mobile Refuge Chamber, Static Analysis, Structure Design

References

[1] Shou Binan, Yang Guoyi, Xu Feng. GB150-2011 The Standard Definition of Pressure Vessel[M]. Beijing: Xinhua Press, (2012).

[2] Standardization Technical Committee of National Pressure Vessel, JB4732-1995, Steel Pressure Vessel- Analysis and Design Standards.

[3] National Administration of Machinery Industry, State Petroleum and Chemical Industry, JB/T4700~4707-2000, Pressure Vessel Flange.

[4] Liu Hongwen, Mechanics of Materials I, version 4 [M]. Beijing: Higher Education Press, (2004).
