Metallurgical and Engineering Challenges in Magnesium Extrusion

Abstract:

AZ 31 Magnesium alloy was extruded under industrial conditions into both a solid shape and a hollow profile. A microstructure analysis of the solid shape revealed a bimodal grain distribution. The FEM process simulation was performed for double hat hollow profile, extruded through an eight-port-hole die using the modified flow stress model from literature. This allowed us to make a prediction of the extrusion process state variables. Additionally, a numerical simulation revealed some shortcomings in terms of a lack of predictive capabilities for extrusion welding. The integrity of the welds was analyzed using metallography techniques. The search for better mechanical properties has propelled alloy development research. Workability evaluations of new Magnesium alloys ZE20, ZE50 and ZE80 containing Zinc and Cerium were performed using compression tests under various temperature and strain rate conditions.

• Periodical: Key Engineering Materials (Volume 585)
• Pages: 3-10
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.585.3
• Online since: December 2013
• Authors: Wojciech Z. Misiolek
• Keywords: Extrusion, Extrusion Welding, Mg Alloy, Microstructure, Rare Earth Alloying Additions

References

[1] C. Davies, M.R. Barnett, Expanding the Extrusion Limits of Wrought Magnesium Alloys, JOM, vol. 56, (2004), pp.22-24.

DOI: 10.1007/s11837-004-0121-7

[2] S.R. Claves, W. Z. Misiolek, D.B. Williams, Modeling and characterization of localized strain in aluminum alloys, Proc. Mat. Solutions Conf., ASM International, Indianapolis, 2001, pp.282-289.

[3] W. Bochniak, Instability of dislocation substructure and its effect on the mechanical properties of deformed metals, Zeitschrift fuer Metallkunde/ Materials Research and Advanced Techniques, vol. 90, (1999), pp.153-158.

[4] H.E. Deve, R.J. Asaro, Development of plastic failure modes in crystalline materials: Shear bands in fcc polycrystals, Metallurgiical Transactions A, vol. 20A, (1989), pp.579-593.

DOI: 10.1007/bf02667576

[5] B.F. Gerard, L. De Pari Jr., W.Z. Misiolek, Microstructural gradients in an industrial magnesium alloy AZ31 extrusion, Steel Research International, 79, vol. 1, (2008), pp.704-711.

[6] S.M. Fatemi-Varzaneh, A. Zarei-Hanzaki, H. Beladi, Dynamic recrystallization in AZ31 magnesium alloy, Materials Science and Engineering A, vol. 456, (2007), pp.52-57.

DOI: 10.1016/j.msea.2006.11.095

[7] J. Bohlen, S.B. Yi, J. Swiostek, D. Letzig, H. G. Brokmeier, K. U. Kainer, Microstructure and texture development during hydrostatic extrusion of magnesium alloy AZ31, Scripta Mat., vol. 53, (2005), pp.259-264.

DOI: 10.1016/j.scriptamat.2005.03.036

[8] Y.V.R.K. Prasad and K.P. Rao, Processing maps for hot deformation of rolled AZ31 magnesium alloy plate: Anisotropy of hot workability, Materials Science and Engineering A, Vol. 487, Nos. 1-2, (2008), pp.316-327.

DOI: 10.1016/j.msea.2007.10.038

[9] C. Dharmendra, K.P. Rao, Y.V.R.K. Prasad, N. Hort and K.U. Kainer, Hot workability analysis with processing map and texture characteristics of as-cast TX32 magnesium alloy, Journal of Materials Science, Vol. 48, Issue 15, (2013), pp.5236-5246.

DOI: 10.1007/s10853-013-7314-9

[10] L. De Pari Jr., W.Z. Misiolek, J.H. Forsmark, A.A. Luo, Flow Stress Numerical Modeling for Large Strain Deformation in Magnesium, Computer Methods in Materials Science, Vol. 10, (2010), No. 2. 108-129.

[11] Y. Xu, W.Z. Misiolek, Numerical Modeling of Extrusion Welding in Magnesium Alloys, Progress in Extrusion Technology and Simulation of Light Metal Alloys, ICEB 2011, edited by L. Tomesani and L. Donati, (2011) pp.159-172.

DOI: 10.4028/www.scientific.net/kem.491.159

[12] L. De Pari Jr., Private Communication.

[13] A. J. Thome, W. Z. Misiolek, A. A. Luo, Workability Evaluation of New Mg-Zn-Ce Alloys, Mg 2012: 9th International Conference on Magnesium Alloys and their Applications, edited by W.J. Poole and K.U. Kainer, (2012) pp.703-708.
