Cu-SiC_p Composites as Advanced Electronic Packaging Materials

Abstract:

The demand for advanced thermal management materials such as silicon carbide particles reinforced copper matrix (Cu-SiC_p) composites is increasing due to the stringent design requirement in the electronic packaging industries. High interest on Cu-SiC_p composites is highlighted by the high thermal conductivity and low coefficient of thermal expansion (CTE) properties. However, the thermal properties of the Cu-SiC_p composites are constrained by the bonding between the copper matrix and the silicon carbide particles (SiC_p) reinforcement. In the powder metallurgical (PM) methodology in particular, the bonding between the two constituents is weak, thus demoting the thermal properties of the Cu-SiC_p composites. In order to improve the interface bonding, the SiC_p were copper coated via electroless coating process. Based on the experimental results and findings, a continuous copper deposition on the SiC_p was obtained via the electroless plating process. The copper film was found to be high in purity and homogeneously deposited on the SiC_p surfaces. The CTE values of the Cu-Coated Cu-SiC_p composites were found significantly lower than those of the non-Coated Cu-SiC_p composites and were in agreement with Kernels model which accounts for both the shear and isostatic stresses developed in the component phases.

You might also be interested in these eBooks

Advanced Materials Engineering and Technology II

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 594-595)

Pages:

852-856

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.594-595.852

Citation:

Cite this paper

Online since:

December 2013

Authors:

K. Azmi, M.N. Derman, A.M. Mustafa Al Bakri, A.V. Sandu

Keywords:

Electroless Copper, Electronic Packaging Materials, Metal Matrix Composite (MMC)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. D.L. Chung: Composite Materials for Electronic Functions (Trans Tech Publication, United States of America 2000).

Google Scholar

[2] L. C. Davis and B. E. Artz: J. Appl. Phys. Vol. 77 (1995) pp.4954-4960.

Google Scholar

[3] T. Schubert, A. Brendel, K. Schmid, T. Koeck, L. Ciupinski, W. Zielinski, B. Kieback, Interfacial design of Cu/SiC composites prepared by powder metallurgy for heat sink applications, Composites Part A 38 (2007) 2398-2403.

DOI: 10.1016/j.compositesa.2007.08.012

Google Scholar

[4] S. Elomari, M. D. Skibo, A. Sundarrajan and H. Richards: Compos. Sci. Technol. Vol. 58 (1998) pp.369-376.

Google Scholar

[5] K. M. Shu, and G. C. Tu: Mater. Sci. Eng. A Vol. 349 (2003) pp.236-247.

Google Scholar

[6] Y. Shacham-Diamand, A. Inberg, Y. Sverdlov, V. Bogush, N. Croitoru, H. Moscovich and A. Freeman: Electrochim. Acta Vol. 48 (2003) pp.2987-2996.

DOI: 10.1016/s0013-4686(03)00364-5

Google Scholar

[7] S. Y. Chang, J. H. Lin, S. J. Lin and T. Kattamis: Metall. Mater. Trans. A Vol. 30 (1999) pp.1119-1136.

Google Scholar

[8] R. Veleva: Surf. Coat. Technol. Vol. 29 (1986) pp.87-93.

Google Scholar

[9] E. Norkus, A. Vaskelis, J. Jaciauskiene, I. Stalnioniene and G. Stalnionis: Electrochim. Acta Vol. 51 (2006) pp.3495-3499.

Google Scholar

[10] M. Oita, M. Matsuoka and C. Iwakura: Electrochim. Acta Vol. 42 (1997) pp.1435-1440.

Google Scholar

[11] G. O. Mallory and J. B. Hajdu: Electroless Plating - Fundamentals and Applications, (William Andrew Publishing/Noyes, United States of America 1990).

Google Scholar
