Enhancement of Energy Storage Properties in PLZST Cramics with Different Zr/Sn Ratios

Abstract:

The effect of Zr/Sn ratio on the dielectric and energy storage properties of lanthanum modified lead zirconate stannate titanate (PLZST) ceramics with compositions located near the boundary between antiferroelectric and ferroelectric phases was studied. Microstructural observation indicated that all the samples had a uniform morphology with pure perovskite phase and the average grain size reduced obviously with increasing Zr/Sn ratio. As the Zr/Sn ratio increased, the dielectric constant increased and the transition temperature T_m shifted to higher temperature. All the PLZST ceramics exhibited double hysteresis loops. The maximum polarization increased, while the switching field decreased when the Zr/Sn ratio increased. The variations of Zr/Sn ratio had little impact on remanent polarization. As a result, both charged energy density and discharged energy density increased with increasing Zr/Sn ratio. A high energy storage density of 1.75 J/cm³ was achieved in the PLZST ceramics with the Zr/Sn ratio of 82.5/7.5 at 9 kV/mm.

• Periodical: Key Engineering Materials (Volumes 602-603)
• Pages: 916-920
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.602-603.916
• Online since: March 2014
• Authors: Qian Zhang, Yong Zhang*, Xiao Lin Liu, Xiao Zhen Song, Jia Zhu
• Keywords: Dielectric Property, Energy Storage Density, Microstructure, PLZST Ceramics, Zr/Sn Ratio

References

[1] J. Wang, T. Yang, S. Chen, G. Li, High Energy Storage Density Performance of Ba, Sr-modified Lead Lanthanum Zirconate Titanate Stannate Antiferroelectric Ceramics, Mater. Res. Bull. 48 (2013) 3847-3849.

DOI: 10.1016/j.materresbull.2013.05.083

[2] X. Hao, Y. Wang, L. Zhang, L. Zhang, S. An, Composition-dependent dielectric and energy-storage properties of (Pb, La)(Zr, Sn, Ti)O3 antiferroelectric thick films, Appl. Phys. Lett. 102 (2013) 163903.

DOI: 10.1063/1.4802794

[3] W.S. Hackenberger, S. Kwon, U.S. Patent US 7, 884, 042 B2. (2011).

[4] Q. Zhang, T. Yang, Y. Zhang, J. Wang, X. Yao, Enhanced antiferroelectric stability and electric-field-induced strain properties in rare earth-modified Pb(Zr0. 63Sn0. 26Ti0. 11)O3 ceramics, Appl. Phys. Lett. 102 (2013) 222904.

DOI: 10.1063/1.4809934

[5] S.E. Park, M.J. Pan, K. Markowski, S. Yoshikawa, L.E. Cross, Electric field induced phase transition of antiferroelectric lead lanthanum zirconate titanate stannate ceramics, J. Appl. Phys. 82 (1997) 1798-1803.

DOI: 10.1063/1.365982

[6] N.G. Pai, B. Xu, L.E. Cross, Compositional dependence of electrical properties in PLZST thin films, Integrated Ferroelectrics 22 (1998) 501-513.

DOI: 10.1080/10584589808208069

[7] Y. Zhang, J. Huang, T. Ma, X. Wang, C. Deng, X. Dai, Sintering Temperature Dependence of Energy-Storage Properties in (Ba, Sr)TiO3 Glass-Ceramics, J. Am. Ceram. Soc. 94 (2011) 1805-1810.

DOI: 10.1111/j.1551-2916.2010.04301.x

[8] S.E. Park, K. Markowski, S. Yoshikawa, L.E. Cross, Effect on electrical properties of barium and strontium additions in the lead lanthanum zirconate stannate titanate system, J. Am. Ceram. Soc. 80 (1997) 407-412.

DOI: 10.1111/j.1151-2916.1997.tb02845.x

[9] X. Chou, J. Zhai, H. Jiang, X. Yao, Dielectric properties and relaxor behavior of rare-earth (La, Sm, Eu, Dy, Y) substituted barium zirconium titanate ceramics, J. Appl. Phys. 102 (2007) 084106.

DOI: 10.1063/1.2799081

[10] M.S. Mirshekarloo, K. Yao, T. Sritharan, Large strain and high energy storage density in orthorhombic perovskite, (Pb0. 97La0. 02)(Zr1-x-ySnxTiy)O3 antiferroelectric thin films, Appl. Phys. Lett. 97 (2010) 142902.

DOI: 10.1063/1.3497193

[11] S. Jiang, L. Zhang, G. Zhang, S. Liu, J. Yi, X. Xiong, Y. Yu, J. He, Y. Zeng, Effect of Zr: Sn ratio in the lead lanthanum zirconate stannate titanate anti-ferroelectric ceramics on energy storage properties, Ceram. Int. 39 (2012) 5571-5575.

DOI: 10.1016/j.ceramint.2012.12.071

[12] Q. Zhang, Y. Zhang, T. Yang, S. Jiang, J. Wang, S. Chen, G. Li, X. Yao, Effect of compositional variations on phase transition and electric field-induced strain of (Pb, Ba)(Nb, Zr, Sn, Ti)O3 Ceramics, Ceram. Int. 39 (2013) 5403-5406.

DOI: 10.1016/j.ceramint.2012.12.047

[13] Y.X. Li, T.Q. Yang, J.F. Wang, K. Wei, G. Li, Influence of Zr/Sn Ratio Electric Properties of PLZST Ceramic, Key Eng. Mater. 547 (2013) 101-105.

DOI: 10.4028/www.scientific.net/kem.547.101

[14] H.R. Jo, C.S. Lynch, Effects of compositional modification in lead lanthanum zirconate stannate titanate ceramics on electric energy storage properties, Proc. of SPIE. 8689 (2013) 868908.

DOI: 10.1117/12.2013783

[15] Q. Zheng, T. Yang, K. Wei, J. Wang, X. Yao, Effect of Sn: Ti variations on electric filed induced AFE-FE phase transition in PLZST antiferroelectric ceramics, Ceram. Int. 38 (2012) S9-S12.

DOI: 10.1016/j.ceramint.2011.04.037

[16] L. Wang, Q. Li, L. Xue, X. Liang, Effect of Ti4+: Sn4+ ratio on the phase transition and electric properties of PLZST antiferroelectric ceramics, J. Mater. Sci. 42 (2007) 7397-7401.

DOI: 10.1007/s10853-007-1839-8

[17] Q. Zhang, T. Yang, Y. Zhang, X. Yao, Phase transition and electric field induced strain properties in Sm modified lead zirconate stannate titanate based antiferroelectric ceramics, J. Appl. Phys. 113 (2013) 244103.

DOI: 10.1063/1.4812375
