3D Numerical Simulation of Friction Stir Welding of Lap Joints Using an Arbitrary Lagrangian Eulerian Formulation

Abstract:

The numerical simulation of Friction Stir Welding (FSW) is carried out using an Arbitrary Lagrangian or Eulerian (ALE) formulation. Its computational cost is reduced by appealing to the parallel version recently developed within the Forge software. The accuracy of the numerical model is increased by enhancing the state variables remapping algorithm and by introducing a better suited time integration scheme based on the cylindrical coordinates. The pin and shoulder threads are modelled in order to account for this crucial phenomenon on material heating. The developed model provides quite satisfactory temperature fields for the FSW of a butt joint of 6061 aluminium, as compared to experimental results. It allows simulating welding defects such as tunnels holes or flashes. The study then focuses on numerical simulations and experimental measurements of a lap joint of a 7175 aluminium sheet on a 2024 aluminium sheet for an aeronautical application.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1528-1535
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1528
• Online since: May 2014
• Authors: Sabrina Gastebois*, Lionel Fourment
• Keywords: Aeronautics, ALE Formulation, Butt Joint, Friction Stir Welding (FSW), Lap Joint, Numerical Simulation

References

[1] J. -H. Cho, D. E. Boyce, and P. R. Dawson, Modelling of strain hardening during friction stir welding of stainless steel, Modelling and Simulation in Materials Science and Engineering, vol. 15, no. 5, p.469–486, Sep. (2007).

DOI: 10.1088/0965-0393/15/5/007

[2] D. Jacquin, B. de Meester, a. Simar, D. Deloison, F. Montheillet, and C. Desrayaud, A simple Eulerian thermomechanical modeling of friction stir welding, Journal of Materials Processing Technology, vol. 211, no. 1, p.57–65, Jan. (2011).

DOI: 10.1016/j.jmatprotec.2010.08.016

[3] D. E. Boyce, P. R. Dawson, B. Sidle, and T. Gnäupel-Herold, A multiscale methodology for deformation modeling applied to friction stir welded steel, Computational Materials Science, vol. 38, no. 1, p.158–175, Nov. (2006).

DOI: 10.1016/j.commatsci.2006.01.021

[4] P. Carlone and G. S. Palazzo, A Numerical and Experimental Analysis of Microstructural Aspects in AA2024-T3 Friction Stir Welding, Key Engineering Materials, vol. 554–557, p.1022–1030, Jun. (2013).

DOI: 10.4028/www.scientific.net/kem.554-557.1022

[5] E. Feulvarch, J. -C. Roux, and J. -M. Bergheau, A simple and robust moving mesh technique for the finite element simulation of Friction Stir Welding, Journal of Computational and Applied Mathematics, vol. 246, p.269–277, Jul. (2013).

DOI: 10.1016/j.cam.2012.07.013

[6] M. Chiumenti, M. Cervera, C. Agelet de Saracibar, and N. Dialami, Numerical modeling of friction stir welding processes, Computer Methods in Applied Mechanics and Engineering, vol. 254, p.353–369, Feb. (2013).

DOI: 10.1016/j.cma.2012.09.013

[7] G. Buffa, L. Fratini, S. Pellegrino, and F. Micari, On the Field Variables Influence on Bonding Phenomena during FSW Processes: Experimental and Numerical Study, Key Engineering Materials, vol. 549, p.484–491, Apr. (2013).

DOI: 10.4028/www.scientific.net/kem.549.484

[8] H. Schmidt and J. Hattel, A local model for the thermomechanical conditions in friction stir welding, Modelling and Simulation in Materials Science and Engineering, vol. 13, no. 1, p.77–93, Jan. (2005).

DOI: 10.1088/0965-0393/13/1/006

[9] L. Fourment and S. Guerdoux, 3D numerical simulation of the three stages of Friction Stir Welding based on friction parameters calibration, International Journal of Material Forming, vol. 1, no. S1, p.1287–1290, Apr. (2008).

DOI: 10.1007/s12289-008-0138-5

[10] S. Philippe, L. Fourment, and P. Montmitonnet, Application of the Arbitrary Lagrangian Eulerian formulation to the numerical simulation of stationary forming processes with dominant tangential material motion., Steel Research International, vol. 2, no. 2, p.571–578, (2008).

[11] L. Fourment, S. Gavoille, U. Rippert, and K. Kpodzo, Efficient formulations for quasi-steady processes simulations: Multi-mesh method, arbitrary Lagrangian or Eulerian formulation and free surface algorithms, in 11th International Conference on Numerical Methods in Industrial Forming Processes (Numiform), (2013).

DOI: 10.1063/1.4806837

[12] M. Assidi, L. Fourment, S. Guerdoux, and T. Nelson, Friction model for friction stir welding process simulation: Calibrations from welding experiments, International Journal of Machine Tools and Manufacture, vol. 50, no. 2, p.143–155, Feb. (2010).

DOI: 10.1016/j.ijmachtools.2009.11.008

[13] G. Losilla, P. Montmitonnet, M. Bouzaiane, and P. Clément, Modélisation du laminage circulaire par éléments finis., pem. utbm. fr, vol. 33, no. 0, p.2–5, (2002).

[14] T. Nagata, Simple local interpolation of surfaces using normal vectors, Computer Aided Geometric Design, vol. 22, no. 4, p.327–347, May (2005).

DOI: 10.1016/j.cagd.2005.01.004
