Investigation of the Spring-In of a Pultruded L-Shaped Profile for Various Processing Conditions and Thicknesses

Abstract:

In this study, a thermo-mechanical finite element model is developed to predict the spring-in of an industrially pultruded L-shaped profile made of glass/polyester composite. The resin curing kinetics are obtained from the differential scanning calorimetry (DSC) experiments. The development of the resin modulus is derived using the dynamic mechanical analysis (DMA) tests and the effective mechanical properties of the processing composite are calculated using a micromechanical model. The temperature and degree of cure distributions are obtained in a three dimensional (3D) thermo-chemical anlaysis using the finite element method (FEM). The process induced distortions are then calculated using these distributions in a 2D quasi-static mechanical analysis in which generalized plane strain elements are utilized. The predicted spring-in pattern at the end of the process is found to agree quite well with the one observed for the real pultruded parts in a commercial pultrusion company. In addition, the effects of the pulling speed and the part thickness on the spring-in formations are investigated using the proposed numerical simulation tool. It is found that the magnitude of the spring-in increases with an increase in the pulling speed and part thickness.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 273-279
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.273
• Online since: May 2014
• Authors: Ismet Baran*, Jesper Hattel, Remko Akkerman
• Keywords: Curing, DMA, DSC, Finite Element Analysis (FEA), Pultrusion, Spring-In

References

[1] Star TF. Pultrusion for engineers. CRC Press; (2000).

[2] Moschiar SM, Reboredo MM, Larrondo H, Vazquez A. Pultrusion of epoxy matrix composites: pulling force model and thermal stress analysis. Polymer Composites 1996; 17(6): 850-858.

DOI: 10.1002/pc.10678

[3] Carlone P, Baran I, Hattel JH, Palazzo GS. Computational Approaches for Modeling the Multiphysics in Pultrusion Process. Advances in Mechanical Engineering, vol. 2013, Article ID 301875, 14 pages, 2013. doi: 10. 1155/2013/301875.

DOI: 10.1155/2013/301875

[4] Valliappan M, Roux JA, Vaughan JG, Arafat ES. Die and post-die temperature and cure in graphite-epoxy composites. Compos Part B-Eng 1996; 27: 1-9.

DOI: 10.1016/1359-8368(95)00001-1

[5] Chachad YR, Roux JA, Vaughan JG, Arafat E. Three-dimensional characterization of pultruded fiberglass-epoxy composite materials. J Reinf Plast Comp 1995; 14: 495-512.

DOI: 10.1177/073168449501400506

[6] Baran I, Hattel JH, Tutum CC. Thermo-Chemical Modelling Strategies for the Pultrusion Process. App Compos Mat. 2013; 20(6): 1247-1263.

DOI: 10.1007/s10443-013-9331-x

[7] Baran I, Tutum CC, Hattel JH. The effect of thermal contact resistance on the thermosetting pultrusion process. Compos Part B: Eng 2013; 45: 995-1000.

DOI: 10.1016/j.compositesb.2012.09.049

[8] Carlone P, Palazzo GS, Pasquino R. Pultrusion manufacturing process development by computational modelling and methods. Math Comput Model 2006; 44: 701-709.

DOI: 10.1016/j.mcm.2006.02.006

[9] Carlone P, Palazzo GS. Pultrusion manufacturing process development: Cure optimization by hybrid computational methods. Comput. Math. Appl. 2007; 53: 1464-1471.

DOI: 10.1016/j.camwa.2006.02.031

[10] Baran I, Tutum CC, Hattel JH. Reliability estimation of the pultrusion process using the firstorder reliability method (FORM). App Compos Mat. 2012; 20: 639-653.

DOI: 10.1007/s10443-012-9293-4

[11] Baran I, Tutum CC, Hattel JH. Optimization of the thermosetting pultrusion process by using hybrid and mixed integer genetic algorithms. App Compos Mat. 2012; 20: 449-463.

DOI: 10.1007/s10443-012-9278-3

[12] Baran I, Tutum CC, Nielsen MW, Hattel JH. Process induced residual stresses and distortions in pultrusion. Compos Part B: Eng 2013; 51: 148-161.

DOI: 10.1016/j.compositesb.2013.03.031

[13] ABAQUS 6. 11 Reference Guide. Dassault Systems (2011).

[14] Johnston A. An Integrated Model of the Development of Process-Induced Deformation in Autoclave Processing of Composites Structures, Ph.D. thesis, The University of British Columbia, Vancouver (1997).

[15] Bogetti TA, Gillespie Jr JW. Process-induced stress and deformation in thick-section thermoset composite laminates. J Compos Mater, 1992; 26(5): 626-660.

DOI: 10.1177/002199839202600502

[16] Akkerman R. On the properties of quasi-isotropic laminates. Compos part B: Eng, 2002; 33: 133- 140.
