Influence of Plasma Channel Change on the Surface Topology in the Electrical Discharge Machining

Abstract:

For the EDM, it is important that the surface topology can be determined for given process parameters in advance. Simulations with constant plasma channel radius are very inaccurate and only give a limit of thermally-influenced zone to. Many functional relationships of the temporal change of the plasma channel are only for small time periods and do not reflect properties of the dielectric. In the paper is shown how various properties of the dielectric, contribute to the change of the plasma channel and the plasma channel as different behaviors can be treated with one simulation program. The maximum thermal load may be calculated by selective application of simulation, but also the topologies through moving or split plasma channels. This extended simulation is important because in the micro-EDM process instabilities leading to the splitting of the plasma channels. The simulations are reviewed on the basis of individual discharges and corrected corresponding weighting factors.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 664-670
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.664
• Online since: May 2014
• Authors: Hans Peter Schulze*, Katharina Mecke
• Keywords: Micromachining, Plasma Channel, Spark Erosion

References

[1] H. -P. Schulze, H. Juhr, R. Haas, Use of additional needle pulse using electrical discharge machining, 14th International Conference on Material Forming – Melville, NY; American Institute of Physics (2011), pp.1344-1349.

DOI: 10.1063/1.3589703

[2] H. -P. Schulze, M. Läuter, W. Rehbein, K. Mecke, G. Wollenberg, Channel spreading during the spark discharge for selected conditions and working fluids. 2003 Annual Report Conference on Electrical Insulation and Dielectric Phenomena. Albuquerque, NM, USA, 19-22 October (2003).

DOI: 10.1109/ceidp.2003.1254852

[3] H. -P. Schulze, G. Wollenberg, M. Läuter, M. Storr, W. Rehbein, Measurement equipment for investigation of the influence of viscosity of dielectric fluids on spark erosion. IEEE Transactions on dielectrics and electrical insulation [New York] 10 (2003).

DOI: 10.1109/tdei.2003.1255776

[4] H. -P. Schulze, Leone, M., O. Kröning, W. Schätzing, Simulation of thermal effects for electrical discharge machining. Nonconventional technologies review, (2007) Iasi, Romania, Vol. 1, pp.103-108.

[5] H. -P. Schulze, W. Schätzing, Influences of different contaminations on the electro-erosive and the electrochemical micro-machining. Procedia CIRP (2013), (ISEM XVII, Leuven, Belgium), pp.58-63.

DOI: 10.1016/j.procir.2013.03.014
