Investigation on Internal Stress of SU-8 Photoresist Film

Abstract:

In this paper, substrate curvature method was adopted and a theory model based on Stoneys formula was built for obtaining the internal stress of SU-8 film. The effect of substrate diameter, film thickness and post-baked temperature on substrate curvature ratio was investigated by ANSYS simulation. The analytical result shows that post-baked temperature is the main effect factor on internal stress of SU-8 film. In addition, internal stresses of SU-8 at three different post-temperatures (55°C, 70°C and 85°C) are measured. The results show that the experimental results greatly agreed with simulation analytical results. It means the internal stress of SU-8 film can be accurately described by the theory model, which provides a basis for the quantitative analysis of the internal stress in SU-8 film.

• Periodical: Key Engineering Materials (Volume 613)
• Pages: 251-258
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.613.251
• Online since: May 2014
• Authors: Xiao Lei Zhang, Li Qun Du*, Shen Miao Zhu
• Keywords: ANSYS Simulation, Internal Stress, Stoneys Formula, SU-8 Photoresist, Substrate Curvature Method

References

[1] L.G. Zhang, D. Chen, F. Yang and Y.G. Li, Research on SU-8 resist photo-lithography process, " Opt Prec Eng, 10 (2002) 266-269. (in Chinese).

[2] B. Li, M. Liu and Q.F. Chen, Low-stress ultra-thick SU-8 UV photolithography process for MEMS, J. Microlith., Microfab., Microsyst, 4 (2005) 043008.

DOI: 10.1117/1.2117108

[3] H. Lorenze, M. Despont, N. Fahrni, J. Brugger, P. Vettiger and P. Renaud, High-aspect-ratio, ultrathick, negative-tone near-UV photoresist and its applications for MEMS, Sens. Actuators, A., 64 (1998) 33-39.

DOI: 10.1016/s0924-4247(98)80055-1

[4] H.K. Chang, Y.K. Kim, UV-LIGA process for high aspect ratio structure using stress barrier and C-shaped etch hole, Sens. Actuators, A., 84 (2000) 342-350.

DOI: 10.1016/s0924-4247(00)00408-8

[5] J.D. Williams, W.J. Wang, Study on the postbaking process and the effects on UV lithography of high aspect ratio SU-8 microstructures, J. Microlith., Microfab., Microsyst, 3 (2004) 563-568.

DOI: 10.1117/1.1792650

[6] X.H. Zheng, D. Zhu, Application of fuzzy neural network to optimizing UV-LIGA process, " Optics and Precision Engineering, 14 (2006) 139-144. (in Chinese).

[7] B. Kampfe, Investigation of Residual Stresses in Microsystems Using X-Ray Diffraction, Mater. Sci. Eng., 288 (2000) 119-125.

[8] M.S. Li, L. Xin, J.K. Yu and T.F. Li, Measurements of Residual Stress in Oxide Scales by Raman Spectroscopy, Journal of Chinese Society for Corrosion and Protection, 19 (1999) 185-188. (in Chinese).

[9] J. Qian, C. Liu, D.C. Zhang and Y.P. Zhao, Residual Stresses in Micro-Electro Mechanical Systems, Journal of Mechanical Strength, 23 (2001) 393-401. (in Chinese).

[10] G.G. Stoney, The Tension of Metallic Films Deposited by Electrolysis, Proc. Roy. Soc. London, 82 (1909) 172-175.

[11] S.S. Wang, J. Chen, D.C. Li, Y. B. Huang and Z.H. Li, A Highly Sensitive Local Curvature Metrology for Internal Stress Detection in Thin Films, Chin J Semiconductors, 27 (2006) 1129–1135. (in Chinese).

[12] C.A. Klein, How Accurate are Stoney's Equation and Recent Modifications, J. Appl. Phys., 88 (2000) 5487-5489.
