Characterization and Correction of Geometric Errors Induced by Thermal Drift in CT Measurements

Abstract:

The occurrence of thermal drift in industrial computed tomography (CT) systems has been reported as a significant source of error on geometrical evaluations. During CT-scans, heating inside the cabinet and varying environmental conditions may affect the position of the focal spot and distort the manipulator system, leading to relative displacement of X-ray projections and distortions in the reconstructed 3D image. This paper presents an experimental investigation on influence of the thermal effects on dimensional CT measurements. A correction method based on the manipulation of the projections was developed and evaluated. The method consists in repeating the acquisition of first projection at the end of the scan and calculating the displacement vector between these projections. The remaining projections are then corrected proportionally to this displacement. The results showed a significant reduction of the roundness deviation values measured on a precision sphere after the correction.

• Periodical: Key Engineering Materials (Volume 613)
• Pages: 327-334
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.613.327
• Online since: May 2014
• Authors: Fabrício Borges de Oliveira, Maurício de Campos Porath, Vitor Camargo Nardelli, Francisco Augusto Arenhart, Gustavo Daniel Donatelli
• Keywords: Computed Tomography, Dimensional Metrology, Thermal Drift, Thermal Errors
