A Novel Experimental Design to Obtain Forming Limit Diagram of Aluminium Alloys for Solution Heat Treatment, Forming and In-Die Quenching Process

Abstract:

Solution heat treatment, forming and in-die quenching (HFQ) is a patented process to form complex shape metal components at a high efficiency and a low cost. Conventional experiment approaches to determine forming limit curves (FLCs) at different strain paths are not applicable for the HFQ forming process. A novel biaxial tensile test rig is designed to overcome the difficulties and determine the FLCs at high temperatures based on the commercial Gleeble machine. This test device employs the circle plate and connecting rod mechanism in order to achieve different strain states, such as uniaxial tension, plane strain and biaxial tension. Resistance heating and air cooling are adopted to obtain an isothermal environment and to control cooling rates in Gleeble respectively. The designs of the cruciform specimen for this test are also introduced in this paper.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 241-248
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.241
• Online since: September 2014
• Authors: Zhu Tao Shao*, Qian Bai, Jian Guo Lin
• Keywords: Constant Strain Rate, Controllable Cooling Rate, Forming Limit Diagram (FLD), HFQ Forming, Novel Experimental Design
