A Cohesive Zone Model for Simulation of the Bonding and Debonding in Metallic Composite Structures - Experimental Validations

Abstract:

Flexible and economic production of composite structures which include functional layersrequires new manufacturing techniques. Joining by plastic deformation is a powerful technique whichis widely used in production processes to create metal composites [1]. The use of plastic deformationin joining processes offers improved accuracy, reliability and environmental safety [2]. The presentstudy deals with modeling of the bonding and debonding behavior in metallic composite structures.Therefore, a general cohesive zone element formulation in the framework of zero-thickness interfaceelements is developed. This enables the accurate and efficient modeling of the interface based on aninterfacial traction-separation law. The paper is concluded by a detailed description of the processsimulation and a comparison of its results with experimental data.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 443-452
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.443
• Online since: September 2014
• Authors: R. Kebriaei*, Alexander Mikloweit, I.N. Vladimirov, Markus Bambach, S. Reese, Gerhard Hirt
• Keywords: Cohesive Zone Element Formulation, Experimental Validations, Numerical Modeling
