Strain Analysis of Parts Produced by Multi-Pass Conventional Metal Spinning

Abstract:

Sheet metal spinning is one of the forming processes based on gradual shaping of metal blank into an axisymetric part by a roller according to a mandrel. Very significant feature of spinning is ability to produce components with high mechanical properties and high quality of surface layers. The paper brings the results of major true strains analysis of mild steel parts produced by CNC multi-pass conventional metal spinning. The influence of the spindle speed, feed rate, workpiece geometry and planar anisotropy of the blank on the strain distribution of formed part is studied by method of grain size measurement. The design of experiment using the Taguchi approach and analysis of variance (ANOVA) is applied to find optimal process parameters.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 427-432
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.427
• Online since: September 2014
• Authors: Peter Šugár*, Jana Šugárová, Ján Petrovič
• Keywords: ANOVA, Metal Spinning, Strain, Taguchi Method
