FFT-Based Modelling of Transformation Plasticity in Polycrystalline Materials during Diffusive Phase Transformation

Abstract:

During phase transformation of steels, when stress is applied, significant large strain can be observed even though the applied stress is smaller than their yield stresses. This phenomenon is called Transformation Plasticity or TRansformation Induced Plasticity (TRIP). Transformation plasticity is known to play an important role during steel producing processes. Although its importance, the phenomenon is not fully understood because of complicated coupled effect of metallurgical, thermal and mechanical behaviour during phase transformation. There are several explanations which account for the phenomenon. Among those, Greenwood-Johnson effect appears to be appropriate explanation especially for diffusive phase transformation. According to Greenwood-Johnson effect, volume change during phase transformation causes locally heterogeneous stress variation and it results in the macroscopic strain together with small applied stress. Along with the notion, Leblond et. al. developed an analytical model which describes well the phenomenon of transformation plasticity. On the other hand, the authors have developed a micromechanical model of polycrystalline materials using discrete FFT (Fast Fourier Transform) method with diffusive phase transformation. In this study, volume expansion along with phase transformation (Greenwood-Johnson effect) is taken into account in the model in order to evaluate the transformation plasticity and micromechanical behaviour during phase transformation. The results by FFT confirm linear relation between applied stress and transformation plastic strain, only if the applied stress does not exceed a half the value of yield stress of the parent phase. In contrast, if applied stress is relatively large (more than half of yield stress of weaker phase), the linear relation is never satisfied. The numerical results are compared with those of experimental and of Leblond model. Furthermore, pre-deformation (deformation just before phase transformation) effect on transformation plasticity is investigated. As a first step, uniaxial tensile followed by phase transformation simulation is carried out. Back stress develops in the course of tensile process and thus the material will be macroscopically anisotropic. It is found that the pre-deformation causes anisotropic dilatation during phase transformation. The mechanism of this anisotropic dilatation will be discussed in the micromechanical point of view.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 687-697
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.687
• Online since: September 2014
• Authors: T. Otsuka*, Renald Brenner, Brigitte Bacroix
• Keywords: Crystal Plasticity, FFT, Steel, Transformation Plasticity

References

[1] G. W. Greenwood , R. H. Johnson, The Deformation of Metals under Small Stresses during Phase Transformations, Proc. Roy. Soc. London, 283A, (1965).

[2] H. Moulinec , P. Suquet, A numerical method for computing the overall response of nonlinear composites with complex microstructure, pp.68-94, (1998).

DOI: 10.1016/s0045-7825(97)00218-1

[3] J. B. Leblond, J. Devaux , J. C. Devaux, Mathematical modelling of transformation plasticity in steels –I: Case of deal-plastic phases, Intl. J. Plasticity, 5, (1989).

DOI: 10.1016/0749-6419(89)90001-6

[4] J. W. Hutchinson, Elastic-plastic behaviour of poly crystalline metals and composites, Proceedings of Royal Society of London, A. 319, (1970).

[5] F. Barbe, R. Quey, L. Taleb , d. C. Souza, Numerical modelling of the plasticity induced during diffusive transformation. An ensemble averaging approach for the case of random arrays of nuclei, European Journal of Mechanics A/Solids, 27, (2008).

DOI: 10.1016/j.euromechsol.2008.01.005

[6] C. Cabus, Etude et modélisation des textures de transformations de phases dans les aciers destinés à l'emboutissage, Doctoral thesis of University Paris 13, (2005).

[7] G. C. Videau, G. Cailletaud , A. Pineau, Experimental study of the transformation induced plasticity in a Cr-Ni-Mo-Al-Ti steel, Journal de Physique IV, colloque C1, Supplèment au J de phisique, III, 6, (1995).

DOI: 10.1051/jp4:1996145

[8] L. Taleb , F. Sidoroff, A micromechanical modeling of the Greenwood-Johnson mechanism in transformation induced plasticity, International Journal of Plasticity, 19, (2003).

DOI: 10.1016/s0749-6419(03)00020-2

[9] C. O. Frederick , P. J. Armstrong, A mathematical representation of the multiaxial Bauschinger effect, Materials at High Temperatures, Vol. 24, No. 1, (2007).

DOI: 10.3184/096034007x207589

[10] L. Taleb , S. Petit, New investigations on transformation induced plasticity and its interaction with classical plasticity, International Journal of Plasticity, 22, (2006).

DOI: 10.1016/j.ijplas.2005.03.012
