Influences of Closed Loop Control Componentson the Performance of Ultra-Precision Machines

Abstract:

At Fraunhofer IPT a test bench has been setup to analyze closed loop control components and their interfaces with focus on their application in ultra-precision machining applications. This paper will present the results of the analysis of feedback and servo drive systems and will give a close inside on the influences of linear scales and analog and digital servo drives for applications in ultra-precision machining. The performed measurements include the analysis of the position accuracy and repeatability (step response test) as well as the determination of the dynamic frequency characteristics (stiffness / compliance) of an air bearing axis. With respect to the aforementioned measurements the tests have been performed under the variation of linear scales (vendor, pitch, signal, sampling frequency, etc.) and servo drives (vendor, switching or linear amplifiers, PWM frequency, control architecture, DC bus voltage, etc.). The paper will give a summary on the results of the analyzed topics, carefully chosen regarding their relevance to ultra-precision machining. Finally, a short outlook to future research work concerning the analysis of CNC controls will be given.

• Periodical: Key Engineering Materials (Volume 625)
• Pages: 207-212
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.625.207
• Online since: August 2014
• Authors: Christian Brecher, Dominik Lindemann*, Christian Wenzel
• Keywords: Closed Loop Control, Encoder, Servo Drive, Ultra-Precision Machining

References

[1] Brecher C, Lindemann D, et al.: Analysis of Control and Servo Drive Systems for the Application in Ultra Precision Machining. Proceedings of the euspen 11th International Conference, Como 2011, pp.303-306.

[2] Brecher C, Lindemann D, Wenzel C.: Influences of Control, Feedback and Servo Drive Systems on Precision Machining. Proceedings of the euspen 12th International Conference, Stockholm 2012, pp.344-347.

[3] Kucera L.: Regelung hochdynamischer Antriebssysteme mit ausgeprägten mechanischen Resonanzen. Proceedings of the SPS/IPC/Drives, Nürnberg 2005, [in German].

[4] Kucera L.: Optimale Architektur zur Regelung hochdynamischer und resonanzbehafteter Antriebe. Proceedings of the SPS/IPC/Drives, Nürnberg 2006, [in German].
