High Resolution Micro-Displacement Sensing Circuit for Rotor Micro-Gyroscope

Abstract:

A novel CMOS interface circuit with high resolution is designed and realized to achieve the integration of interface circuit for liquid suspended rotor micro-gyroscope. The detecting circuit adopts continuous-time current sensing circuit for capacitance measurement. The equivalent output noise power spectral density of phase-sensitive demodulation is 120 nV/Hz1/2. The whole circuitry is realized with 0.5 μm 2P2M CMOS process and its testing results show the circuit has a relative capacitance resolution of 1×10-8, in which the power supply is 18 V and the power consumption is 30 mW. The area of the chip is merely 18.5 mm2.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 538-542
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.538
• Online since: May 2015
• Authors: Ming Yuan Ren*, Xiao Wei Liu, Hai Feng Zhang, Zhi Gang Mao
• Keywords: Capacitance Detection, CMOS Integrated Circuit, Gyroscope, Suspended Rotor

References

[1] F. Wu, G.K. Fedde, and L.R. Carley, IEEE J. Solid. -State Circuits, 39(2004)722-730.

[2] B.V. Amini, R. Abdolvand, and F. Ayazi, IEEE J. Solid. -State Circuits, 41(2006) 2983-2991.

DOI: 10.1109/jssc.2006.884864

[3] H. Kulah, J. Chae, and K. Najafi, IEEE J. Solid. -State Circuits, 41(2006) 352-361.

[4] C.D. Ezekwe and B.E. Boser, IEEE J. Solid. -State Circuits, 43(2008) 3039-3048.

[5] L. Aaltonen and K. Halonen, Sens. Actuators A, Phys., 154(2009) 46-56.
