Advancements in Micro-Structure with Multiple Stress Concentration Region for Bionic Vector Hydrophone

Abstract:

The method of Multiple Stress Concentration Regions (MSCRs) on the surface of MEMS Silicon micro-structure is introduced in order to enhance the sensibility of the hair vector hydrophone without reducing the working bandwidth. The MSCRs with the thickness and width smaller than the rest of the cantilever can produce localized stress concentration when constant force is applied on the structure. ANSYS software has been used as a tool to analyze the effect of different shapes and dimensions on the performance of the micro-structure. The optimum MSCR has been obtained. Results show that compared with the ordinary structure, the sensitivity of the micro-structure with MSCR can be increased by 1.5 times, and the upper limit of bandwidth can be improved from 337Hz to 500Hz. This paper provides a new method to resolve contradiction between the sensitivity and working bandwidth.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 555-560
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.555
• Online since: May 2015
• Authors: Guo Jun Zhang, Peng Zhao, Wen Dong Zhang*
• Keywords: ANSYS, MEMS, Stress Concentration, Vector Hydrophone

References

[1] XUE Chenyang, CHEN Shang, ZHANG Wendong, et al. Design, Fabrication, and Preliminary Characterization of a Novel MEMS Bionic Vector Hydrophone, J. Micro- electronics Journal. 38(2007) 1021-1026.

DOI: 10.1016/j.mejo.2007.09.008

[2] Binzhen Zhang, Hui Qiao, Shang Chen, et al. Modeling and characterization of a micromachined artificial hair cell vector hydrophone, J. Microsyst Technol. 14(2008)821-828.

DOI: 10.1007/s00542-008-0560-0

[3] Linggang Guan, Chenyang Xue, Guojun Zhang, et al. Advancements in technology and design of NEMS vector hydrophone, J. Microsyst Technol. 17(2011) 459-467.

DOI: 10.1007/s00542-011-1272-4

[4] Linggang Guan, Guojun Zhang, Jiao Xu, et al．Design of T-shape vector hydrophone based on MEMS, J. Sensors and Actuators A: Physical. 188(2012) 35-40.

DOI: 10.1016/j.sna.2012.01.018

[5] R Bashir, A Gupta, G W Neudeck, et al. On the design of piezoresistive silicon cantilevers with stress concentration regions for scanning probe microscopy applications, J. Micromech Microeng. 10(2000) 483-491.

DOI: 10.1088/0960-1317/10/4/301

[6] S.M. Firdaus, I.A. Azid, O. Sidek, et al. Enhancing the sensitivity of a mass-based piezoresistive micro-electro-mechanical systems cantilever sensor, J. Micro & Nano Letters. 5(2009) 85-90.

DOI: 10.1049/mnl.2009.0105

[7] S.M. Firdaus, I.A. Azid, O. Sidek, et al. Half Cut Stress Concentration(HCSC)Region Design on MEMS Piezoresistive Cantilever for Sensitivity Enhancement[C]/33rd International Electronic Manufacturing Technology (IEMT)Conference, (2008).

DOI: 10.1109/iemt.2008.5507894

[8] MEI Deqing, WANG Yancheng, CHEN Ziche. Design of piezoresistive micro-cantilever with stress concentration region, J. Nano-technology and Precision Engineering. 5(2007)227-280.

[9] LI Qichang, WANG Guanglong, GAO Fengqi. Design simulation of micro-cantilever with high sensitive SCR. Transducer and Microsystem Technologies. 32(2013) 95-98.

[10] CHEN Shang. Research of MEMS bionic vector hydrophone based on silicon, D. Taiyuan: North University of China, (2008).

[11] XU Jiao, ZHANG Guojun, SHI Guixiong, et al. Advancements in encapsulation of hair vector hydrophone, J. Chinese Journal of Sensors and Actuators. 24(2011) 517-520.
