CAD Modeling and Optimization of the Optimal Geometric Features of a Microdrill

Abstract:

The objective of this paper is to construct a CAD model and to determine the optimal geometric features of a 0.1 mm diameter of microdrill. The CAD model was constructed using Pro/Engineer software by determining the flute of a microdrill mathematically. The cross section comparison between the model and fabricated microdrill was carried out by cutting at different lengths, and the results of the web thickness of the model and the fabricated microdrill were approximately the same. Hence, the CAD Modeling of a microdrill based on determining the flute mathematically by considering both setting angle and profile of a grinding wheel was feasible. The optimal geometric features of a microdrill have been determined by carrying out optimization of the stress/displacement analysis using Pro/Mechanica software so that the maximum stress Von Mises of the microdrill was minimal.

• Periodical: Key Engineering Materials (Volume 649)
• Pages: 66-73
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.649.66
• Online since: June 2015
• Authors: Teshome Mulatie Bogale, Fang Jung Shiou*, Geo Ry Tang
• Keywords: CAD Model, Microdrill, Optimal Geometrical Features, Pro/Mechanica Software

References

[1] L.J. Zheng, C.Y. Wang, L.Y. Fu, L.P. Yang, Y.P. Qu, Y.X. Song, Wear mechanisms of micro-drills during dry high speed drilling of PCB, Journal of Materials Processing Technology, 212 (2012) 1989-(1997).

DOI: 10.1016/j.jmatprotec.2012.05.004

[2] C. Coombs, Printed circuits handbook, McGraw-Hill, New York, (2007).

[3] S. Kaldor, A.M. Rafael, D. Messinger, On the CAD of profiles for cutters and helical flutes - geometrical aspects, CIRP Annals - Manufacturing Technology, 37 (1988) 53-56.

DOI: 10.1016/s0007-8506(07)61584-4

[4] W. -T. Chang, T. -H. Chen, Y. -S. Tarng, Measuring characteristic parameters of form grinding wheels used for microdrill fluting by computer vision, Transactions of the Canadian Society for Mechanical Engineering, 35 (2011) 383-401.

DOI: 10.1139/tcsme-2011-0022

[5] B.K. Hinds, G.M. Treanor, Analysis of stresses in micro-drills using the finite element method, International Journal of Machine Tools and Manufacture, 40 (2000) 1443-1456.

DOI: 10.1016/s0890-6955(00)00007-9

[6] F.J. Shiou, K.H. Hung, Determination of the optimal geometrical features of a microdrill, Applied Mechanics and Materials, 284 (2013) 702-706.

DOI: 10.4028/www.scientific.net/amm.284-287.702

[7] K. -H. Hung, Research on the optimal geometric design of a microdrill based on stress analysis and the flank wear for drilling BGA substrate, National Taiwan University of Science and Technology, (2005).

[8] K.C. Jain, A.K. Chitale, Textbook of production engineering, PHI Learning, (2010).
