The Two Dimensional Microstage Used in Geometric Measurement of Rockwell Diamond Indenter

Abstract:

The Primary Rockwell Hardness Standard System was set up in the Center for Measurement Standards since July 1996 till June 1997. During the period, a compact laser interferometer, HP10737R 3-axis interferometer system was used to measure the effect of pitch and yaw of the Rockwell Hardness standard machine. Considering to increase the performance of hardness measurement, the geometry of the diamond tip has to be determined. In this paper, we will present the results of indenter geometry by μ-CMM (Coordinate Measuring Machine) in CMS.

• Periodical: Key Engineering Materials (Volume 649)
• Pages: 90-96
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.649.90
• Online since: June 2015
• Authors: Sheau Shi Pan, I Chih Ni, Feng Yu Yang
• Keywords: Laser Interferometers, Rockwell Diamond Indenter, Tungsten Sub-Micrometer Tip, μ-CMM (Coordinate Measuring Machine)

References

[1] Song, J., Rudder, F., Vorburger, T., and Smith, J., Microform calibration uncertainties of Rockwell diamond indenters, J. Res. NIST, 100(5), 543-561, (1995).

DOI: 10.6028/jres.100.041

[2] Song, J., Low, S., Zheng, A., Geometric measurement comparisons for Rockwell diamond indenters, in the proceedings of the IMEKO XIX World Congress, Lisbon, Portugal, (2009).

[3] J. Song, S. Low, A. Zheng and P. Gu, Geometrical measurements of NIST SRM Rockwell hardness diamond indenters, in the proceedings of the IMEKO 2010 TC3, TC5 and TC22 Conferences Metrology in Modern Context November 22−25, 2010, Pattaya, Chonburi, Thailand.

[4] Gaoliang Dai, Jian Zhao, Febo Menelao, Konrad Herrmann1, Uwe Brand, Improved methods for accurately calibrating the 3d geometries of Rockwell indenters, in the proceedings of the IMEKO 2010 TC3, TC5 and TC22 Conferences Metrology in Modern Context November 22−25, 2010, Pattaya, Chonburi, Thailand.

[5] Alessandro Germak and Claudio Origlia, New possibility in the geometrical calibration of diamond indenters, in the proceedings of the IMEKO XIX World Congress, Lisbon, Portugal, (2009).

[6] I-Chih Ni, Sheau-shi Pan, Jian-Lin Huang and Sheng-Jui Chen" Geometric measurement of rockwell diamond indenter using traced micro-cmm in CMS", XX IMEKO World Congress Metrology for Green Growth September 9- 14, 2012, Busan, Republic of Korea.

[7] F. Alasia, Procedura per L'allineamento ottico e meccanico del manobarometro HG-5, 1996 IMGC Technical reports.

[8] ASTM E18-89a, Standard test methods for Rockwell hardness and Rockwell superficial hardness of metallic materials, ASTM, New York (1989).

DOI: 10.3403/00197267u

[9] ISO/FDIS 6508-1, 2, 3, Metallic materials-Hardness test-Verification of Rockwell hardness testing machines (Scales A-B-C-D-E-F-G-H-K) , ISO/TC 3 (1999).

DOI: 10.3403/00636903u

[10] Center for Measurement Standards of Industrial Technology Research Institute, The Evaluation of Rockwell Hardness Primary Standard System" series number 07-3-87-0002, (2001).
